Internet #205475241

Model # 24735LF

Store SKU #1001008643

0697285247352

1/2 in. Push-to-Connect Brass Slip Ball Valve

  • Push to Connect system, quick and easy installation in seconds
  • Works on any combination of Copper and CPVC Pipe
  • Lead free DZR brass construction for durability and reliability
$ 20 21
Loading Options

Frequently Bought Together

Frequently Bought Together

Product Overview

Installation requires no use of expensive tools, glues, solders, solvents, or crimping; all you need are pipe cutters.

No Tools Required

Installation requires no use of expensive tools, glues, solders, solvents, or crimping; all you need are pipe cutters.

SharkBite Fittings are compatible with more than 5 pipe types: PEX, Copper, CPVC, PE-RT and HDPE.

Versatility

SharkBite Fittings are compatible with more than 5 pipe types: PEX, Copper, CPVC, PE-RT and HDPE.

Installation is fast and simple within 3 seconds, allowing the job to get done in a snap.

Easy Fast Install

Installation is fast and simple within 3 seconds, allowing the job to get done in a snap. Allows fot the ability to work in tight spaces without having to make structural changes.

Man working with SB

Approved for Underground

Approved for burial applications (wrapping required when burying underground)

SharkBite Fittings are removable with disconnect clips or tongs, which will reduce the risk of installation errors

Error-Proof

SharkBite Fittings are removable with disconnect clips or tongs, which will reduce the risk of installation errors

Installation does not require a dry pipe and there is no need to wait for the pipe to drain, ProLock can be installed on a wet line.

Wet or Dry Applications

Installation does not require a dry pipe and there is no need to wait for the pipe to drain, ProLock can be installed on a wet line.

SharkBite owns the entire manufacturing process, from raw materials to finished product.

Quality you can trust

SharkBite owns the entire manufacturing process, from raw materials to finished product

Full range of fittings and accessories 1/4 in. - 2 in.; Large diameter fittings (1-1/4" - 2") required Stiffener when connection to PEX Pipe.

Versatile Fittings Collection

Full range of fittings and accessories 1/4 in. - 2 in.; Large diameter fittings (1-1/4" - 2") required Stiffener when connection to PEX Pipe

Listed by IAPMO and design certified.

Certified

Listed by IAPMO and design certified and listed to ASSE 1061, CSA B125.3, NSF 372, NSF/ANSI 61, ASTM E84, CAN/ULC S102.2, ASTM, E119, CAN/ULC S101,UL289

Rated to 200°F and 200 PSI

Working Temperature and Pressure

Rated to 200°F and 200 PSI

Made of durable DZR brass

Material

Made of durable DZR brass

Approved for behind-the-wall applications

Behind the Wall

Approved for behind-the-wall applications

25 Year System Warranty

Reliability

25 Year System Warranty

  • Push to Connect system, quick and easy installation in seconds
  • Works on any combination of Copper and CPVC Pipe
  • Lead free DZR brass construction for durability and reliability
The SharkBite 1/2 in. Push-to-Connect Slip Ball Valve is an innovative valve that allows you to make a quick repair or add in ball valve to rigid Copper or CPVC Pipe. The slip ball valve allows up to 2 in. of pipe to be removed allowing for easy installation where rigid pipes do not allow movement. Simply insert the slip coupling on to the pipe and using the SharkBite demount clip to slip the fitting back onto the other end of pipe completing the connection. The slip ball valve is a great item to have handy for emergencies or freeze repairs as well. The SharkBite connection system requires no solder, clamps, unions or glue. Check out the Slip Ball Valve video to see how fast and easy it is to make repairs and add in a ball valve using the SharkBite Push-Fit Slip Ball Valve.
  • Lead free DZR brass construction for durability and reliability
  • Use to connect to any combination of copper and CPVC pipes
  • Innovative push-to-connect design makes for quick and easy installation
  • Push-to-connect fittings require no solder, glue, unions or tools
  • Fitting can be rotated on pipe after installation making it easier to work in tight spaces
  • Designed for potable water distribution as well as hydronic heating applications
  • Corrosion resistant to improve longevity
  • Certified as a manufactured joint and for underground and behind-the-wall applications without access panels
  • Listed by IAPMO and design certified and listed to ASSE 1061/NSF 61
  • Meets all UPC, IPC and cUPC requirements
  • Demount clip allows user to release the fitting from the pipe for convenient installation flexibility (sold separately)
  • Rated to 200°F and 200 psi
  • Adapts to pipe using push-fit connection
  • 1/2 in. pipe insertion depth - 15/16 in.
  • Shop all SharkBite Fittings
  • California residents see Prop 65 WARNINGS

Product Overview

  • Push to Connect system, quick and easy installation in seconds
  • Works on any combination of Copper and CPVC Pipe
  • Lead free DZR brass construction for durability and reliability
Model #: 24735LF
Sku #: 1001008643
Internet #: 205475241

The SharkBite 1/2 in. Push-to-Connect Slip Ball Valve is an innovative valve that allows you to make a quick repair or add in ball valve to rigid Copper or CPVC Pipe. The slip ball valve allows up to 2 in. of pipe to be removed allowing for easy installation where rigid pipes do not allow movement. Simply insert the slip coupling on to the pipe and using the SharkBite demount clip to slip the fitting back onto the other end of pipe completing the connection. The slip ball valve is a great item to have handy for emergencies or freeze repairs as well. The SharkBite connection system requires no solder, clamps, unions or glue. Check out the Slip Ball Valve video to see how fast and easy it is to make repairs and add in a ball valve using the SharkBite Push-Fit Slip Ball Valve.

  • Lead free DZR brass construction for durability and reliability
  • Use to connect to any combination of copper and CPVC pipes
  • Innovative push-to-connect design makes for quick and easy installation
  • Push-to-connect fittings require no solder, glue, unions or tools
  • Fitting can be rotated on pipe after installation making it easier to work in tight spaces
  • Designed for potable water distribution as well as hydronic heating applications
  • Corrosion resistant to improve longevity
  • Certified as a manufactured joint and for underground and behind-the-wall applications without access panels
  • Listed by IAPMO and design certified and listed to ASSE 1061/NSF 61
  • Meets all UPC, IPC and cUPC requirements
  • Demount clip allows user to release the fitting from the pipe for convenient installation flexibility (sold separately)
  • Rated to 200°F and 200 psi
  • Adapts to pipe using push-fit connection
  • 1/2 in. pipe insertion depth - 15/16 in.
  • Shop all SharkBite Fittings
  • California residents see Prop 65 WARNINGS

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand SharkBite SharkBite SharkBite SharkBite
Name 3/4 in. Push-to-Connect x FIP Brass Ball Valve 1/2 in. Push-to-Connect Brass Slip Ball Valve 3/4 in. x 1/2 in. Push-to-Connect Reducing Ball Valve 3/4 in. Push-to-Connect Brass Slip Ball Valve
Price
$17.77
$19.25
$20.87
$23.68
Ratings (111) (257) (31) (257)
Valve Outlet Diameter (in.) .75 0.5 .5 .75
Valve Inlet Diameter (in.) .75 0.5 .75 .75
Connection PTC PTC x PTC PTC PTC x PTC
View Product View Product View Product View Product

Specifications

Dimensions

Inlet Diameter (In.)
1/2
Outlet Diameter (In.)
1/2
Product Depth (in.)
1.13
Product Height (in.)
2
Product Length (in.)
1.13
Product Width (in.)
6.25
Valve Inlet Diameter (in.)
0.5
Valve Outlet Diameter (in.)
0.5

Details

Application
Potable Water
Compatible Pipe Material
Multi-Purpose
Connection
PTC x PTC
Features
Removable
Fitting or Connector Type
Adapter or Coupling
Handle Style
Lever
Indoor/Outdoor
Indoor,Outdoor
Material
Brass
Maximum Pressure (psi)
200
Maximum Working Temperature (F)
200
Maximum working pressure (psi)
200
Pipe or Fitting Product Type
Fittings & Connectors
Product Weight (lb.)
0.464lb
Push to connect
Yes
Push-to-Fit
Yes
Returnable
180-Day
Valve Type
Ball
Valve Use
Water

Warranty / Certifications

Manufacturer Warranty
For warranty information on this product, please call our Internet Customer Service Center at 1-877-700-4242.

Specifications

Dimensions

Inlet Diameter (In.)
1/2
Outlet Diameter (In.)
1/2
Product Depth (in.)
1.13
Product Height (in.)
2
Product Length (in.)
1.13
Product Width (in.)
6.25
Valve Inlet Diameter (in.)
0.5
Valve Outlet Diameter (in.)
0.5

Details

Application
Potable Water
Compatible Pipe Material
Multi-Purpose
Connection
PTC x PTC
Features
Removable
Fitting or Connector Type
Adapter or Coupling
Handle Style
Lever
Indoor/Outdoor
Indoor,Outdoor
Material
Brass
Maximum Pressure (psi)
200
Maximum Working Temperature (F)
200
Maximum working pressure (psi)
200
Pipe or Fitting Product Type
Fittings & Connectors
Product Weight (lb.)
0.464lb
Push to connect
Yes
Push-to-Fit
Yes
Returnable
180-Day
Valve Type
Ball
Valve Use
Water

Warranty / Certifications

Manufacturer Warranty
For warranty information on this product, please call our Internet Customer Service Center at 1-877-700-4242.

Questions & Answers

Can this valve be used with PEX pipe

Can this valve be used with PEX pipe
Asked by: pex
Yes. We used the pex and shark bite on our bathroom faucets
Answered by: Jenn
Date published: 2020-01-14

Which end is a slip end? It's not marked at all on this model 1/2" slip ball valve

Asked by: Dan
each end is a slip end
Answered by: RW
Date published: 2019-11-10

Can I connect it to an existing three quarter inch copper Street elbow? t copperelbow?

Asked by: Pexrhead
My guess would be no. street elbows are too short.
Answered by: lonfu
Date published: 2019-03-06

Which direction does the ball valve face

Asked by: Nap
Level. East to west.
Answered by: Lorenzo
Date published: 2018-10-20
