1/2 in. x 25 ft. Coil White PEX-B Pipe

Includes 25 ft. (39¢ /ft.)
$9.87
  • Flexible, durable piping sytem for hot and cold potable plumbing
  • Highest rated chlorine resistance and 6-month UV resistance
  • Compatible with PEX Crimp and Push-to-Connect fittings
  • See More Details
Store
0 in stock
Text to Me

Product Overview

SharkBite PEX tubing is cross-linked polyethylene tubing for a wide range of residential and commercial plumbing applications. PEX Pipe is durable, flexible and corrosion resistant. Manufactured without an oxygen barrier for potable water systems (available in white, blue, and red). A repeating SharkBite imprint patterns provides a visual aid to determine if the tube has been inserted all the way into the SharkBite Push-to-Connect Fitting. This feature only works if the tubing is cut between the SharkBite imprint patterns. In addition to Potable Water Supply SharkBite PEX meets UL Standard for Plastic Piping in Fire Systems.
  • Strong, flexible, corrosion-resistant pipe
  • Flexibility reduces number of fittings needed to complete a job; reducing cost and leak points
  • Can be installed wet or dry for immediate pressure testing
  • SharkBite imprint pattern provides a visual aid to ensure pipe is fully inserted when using SharkBite push-to-connect fittings
  • SharkBite system provides a variety of connection options, SharkBite PEX can be connected with SharkBite push-to-connect fittings or barbed fittings
  • Listed to NSF 14 and CSA B137.5 for use in potable water systems
  • Meets UL1821 standard for plastic piping for fire systems (3/4 in. and 1 in. only)
  • Manufactured and tested to meet or exceed the requirements of the ASTM F-876/877/2023 and CSA B137.5
  • Shop all SharkBite Fittings

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

1/2 in. x 25 ft. Coil White PEX-B Pipe

Compare Similar PEX Pipe

current product
1/2 in. x 25 ft. Coil White PEX-B Pipe
1/2 in. x 50 ft. Coil Red PEX-B Pipe1/2 in. x 50 ft. Coil Blue PEX-B Pipe3/8 in. x 50 ft. Coil White PEX-B Pipe
BrandSharkBiteSharkBiteSharkBiteSharkBite
Name1/2 in. x 25 ft. Coil White PEX-B Pipe1/2 in. x 50 ft. Coil Red PEX-B Pipe1/2 in. x 50 ft. Coil Blue PEX-B Pipe3/8 in. x 50 ft. Coil White PEX-B Pipe
Price
$987
$1314
$1479
$1747
Ratings
(67)
(21)
(21)
(96)
Nominal Inside Pipe Diameter (In.)1/2"1/2"1/2"3/8"
Product Length (ft.)2550 ft50 ft50 ft
PEX TypeBBBB
ConnectivityPush FitPush FitPush FitPush Fit
Pipe FeaturesFlexibleFlexibleFlexibleFlexible
MaterialCross-Linked Polyethylene (PEX)Cross-Linked Polyethylene (PEX)Cross-Linked Polyethylene (PEX)Cross-Linked Polyethylene (PEX)
ApplicationPotable WaterPotable WaterPotable WaterPotable Water
Actual outside diameter (in.)0.625.5.50.5
Pack Size1111
Actual inside diameter (in.)0.4750.4750.475.350
View ProductView ProductView ProductView Product

Specifications

Dimensions

Actual inside diameter (in.)
0.475
Actual outside diameter (in.)
0.625
Inner Diameter (in.)
0.475
Nominal Inside Pipe Diameter (In.)
1/2"
Outer Diameter (in.)
0.625
Pipe Wall Thickness (In.)
0.075
Product Length (ft.)
25

Details

Application
Potable Water
Color Family
White
Color/Finish
White
Connectivity
Push Fit
Material
Cross-Linked Polyethylene (PEX)
Maximum Flow Rate (gallons per minute)
4.4
Maximum working pressure (psi)
160
Maximum Working Temperature (F)
200
Minimum working temperature (F)
32
Pack Size
1
PEX Type
B
Pipe Features
Flexible
Pipe or Fitting Product Type
Pipe & Tubing
Product Weight (lb.)
3
Returnable
90-Day

Warranty / Certifications

Certifications and Listings
ANSI Certified,CSA Listed,IAPMO Certified
Manufacturer Warranty
For warranty information on this product, please call our Internet Customer Service Center at 1-800-435-4654.
