Internet #202276330

Model # MC4040B1200SECW

Store SKU #636632

Store SO SKU #516939

0783643443518

Siemens

200 Amp 40-Space 40-Circuit Outdoor Combination Meter Combo Load Center

  • Suitable for use only as service entrance equipment
  • Side-by-side construction; Surface mount, EUSERC Compliant
  • For Overhead or Underground feed applications
store icon Loading Buying Options...
package icon Loading Buying Options...
Sorry, but we ran into issues loading these options. Please try refreshing.

Frequently Bought Together

Frequently Bought Together

+
+

Product Overview

  • Suitable for use only as service entrance equipment
  • Side-by-side construction; Surface mount, EUSERC Compliant
  • For Overhead or Underground feed applications
The Siemens 200 Amp 40-Space 40-Circuit Outdoor Combination Main Breaker/Meter Socket Load Center surface mounts and provides NEMA type-3R protection. This combination load center is equipped with a highly conductive copper buss bar and features a painted galvanized steel construction. This load center is designed for use as service entrance equipment only.

Product Overview

  • Suitable for use only as service entrance equipment
  • Side-by-side construction; Surface mount, EUSERC Compliant
  • For Overhead or Underground feed applications
Model #: MC4040B1200SECW
Sku #: 636632
Internet #: 202276330

The Siemens 200 Amp 40-Space 40-Circuit Outdoor Combination Main Breaker/Meter Socket Load Center surface mounts and provides NEMA type-3R protection. This combination load center is equipped with a highly conductive copper buss bar and features a painted galvanized steel construction. This load center is designed for use as service entrance equipment only.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Key Features

Product Overview
Key Features
  • Suitable for use only as service entrance equipment
  • Side-by-side construction; Surface mount, EUSERC Compliant
  • For Overhead or Underground feed applications
The Siemens 200 Amp 40-Space 40-Circuit Outdoor Combination Main Breaker/Meter Socket Load Center surface mounts and provides NEMA type-3R protection. This combination load center is equipped with a highly conductive copper buss bar and features a painted galvanized steel construction. This load center is designed for use as service entrance equipment only.

Product Overview

  • Suitable for use only as service entrance equipment
  • Side-by-side construction; Surface mount, EUSERC Compliant
  • For Overhead or Underground feed applications
Model #: MC4040B1200SECW
Sku #: 636632
Internet #: 202276330

The Siemens 200 Amp 40-Space 40-Circuit Outdoor Combination Main Breaker/Meter Socket Load Center surface mounts and provides NEMA type-3R protection. This combination load center is equipped with a highly conductive copper buss bar and features a painted galvanized steel construction. This load center is designed for use as service entrance equipment only.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar

Compare Similar Products
Brand Eaton Eaton Eaton
Name CH 200 Amp 42-Circuit EUSERC Meter Breaker Outdoor Surface Mount BR 200 Amp 40-Circuit Outdoor EUSERC Meter Breaker Panel BR 200 Amp 40-Circuit Outdoor EUSERC Meter Breaker Panel
Price
$557.27
$766.24
$871.79
Ratings (1) (0) (0)
Mounting type Bolt On Bolt On Bolt On
Maximum Amperage (amps) 200 200 200
Number of Spaces 42 40 40
Voltage (volts) 120/240 120/240 120/240
View Product View Product View Product

Specifications

Dimensions

Load center depth (in.)
33.8
Load center height (in.)
6.0
Load center width (in.)
15.8

Details

Electrical Product Type
Load Center
Indoor/Outdoor
Outdoor
Load Center Type
Main Breaker
Maximum Amperage (amps)
200
Mounting type
Bolt On
Number of Phases
1
Number of Spaces
40
Product Weight (lb.)
54.4lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
1 YEAR

Specifications

Dimensions

Load center depth (in.)
33.8
Load center height (in.)
6.0
Load center width (in.)
15.8

Details

Electrical Product Type
Load Center
Indoor/Outdoor
Outdoor
Load Center Type
Main Breaker
Maximum Amperage (amps)
200
Mounting type
Bolt On
Number of Phases
1
Number of Spaces
40
Product Weight (lb.)
54.4lb
Returnable
90-Day
Voltage (volts)
240

Warranty / Certifications

Certifications and Listings
1-UL Listed
Manufacturer Warranty
1 YEAR

Questions & Answers

Two questions actually. Does the panel accept tandem breakers? With new cables from the meter, ca...

Two questions actually. Does the panel accept tandem breakers? With new cables from the meter, can the main breaker be moved to the top of the panel?
Asked by: Itsalwayssomething
No, MC4040B1200SECW is a 40 space 40 circuit device which means tandem breakers cannot be used. Please note there was a design change moving the main breaker to the bottom of the distribution section. This is shown on the cut sheet at the link below. No modifications can be made. https://s3.amazonaws.com/dcc-data-extract/full_jan2019/asset/COMPAS/Specification%20Sheet/SIE_CS_MC4040B1200SECW.pdf
Answered by: SIEMENS Product Expert
Date published: 2019-03-07

Is this panel a PL or ES series?

Is this panel a PL or ES series?
Asked by: dabi
Neither, actually. PL or ES series load centers do not include meter combinations.
Answered by: SIEMENS Product Expert
Date published: 2018-11-29

What type of breakers does this panel accept?

Asked by: dja
Hi dja, This meter combo accepts Siemens type QP circuit breakers. For example a single pole 20 Amp would be here: http://www.homedepot.com/p/Siemens-20-Amp-Single-Pole-Type-QP-Circuit-Breaker-Q120U/100044919?keyword=Q120U
Answered by: SIEMENS Product Expert
Date published: 2016-07-20
