Internet #206560230

Model #FS140

Store SO SKU #516939

FirstSurge Pro 140kA Whole House Surge Protection Device

  • Let's you know you are protected via LED's & audible alarm
  • Surge current capacity sized for where you live
  • FirstSurge protects any 120/240V branded load center
  • See More Details

Frequently Bought Together

+
+
Price:
$19830

Product Overview

Not long ago, we turned knobs and dials to change TV channels or set wash cycles. Now, we're in the Internet of Things (Iot) era where homeowners are increasingly reliant upon connected devices. To ensure these devices 'just keep working', today's home requires constant surge protection. Knowing when a surge protector needs to be replaced is the KEY to remaining protected. This is why we developed FirstSurge, our commercial class total home surge protector. Installed at your load center, FirstSurge will stop surges before they get into your home. FirstSurge offers three grades of robustness to ensure long operational life depending upon the storm activity where you live. The key to remaining surge protected is knowing when a surge protector needs to be replaced. The gap of time between a surge protector wearing out until it is replaced is the time when your home is vulnerable to being hit by surges. When FirstSurge wears out, its commercial class 3-stage notification diagnostics immediately alerts you that it needs replacing. This type of notification results in a far shorter Mean Time Before Surge Protection Restoration (MTBSPR) when compared to standard whole house protectors equipped only with LED diagnostics. Knowing you're surge protected with commercial class protection gives you peace of mind that your smart appliances and electronics will always be surge protected. Make Siemens FirstSurge the first surge protector installed into your home.
  • When there is a problem, Siemens FirstSurge takes the guesswork out of knowing when it is time to be replaced; an audible alarm beeps, the green LED lights on the device will extinguish and the red service light will flash
  • FirstSurge is equipped with ground reference monitoring notifying you a rare safety hazard exists due to a compromised electrical system neutral to ground bond; in this case an audible alarm will beep, the green LED lights on the device will remain lit, and the red service light will flash
  • FirstSurge pro provides 140,000 Amp of surge current capacity per phase
  • NEMA 3R enclosure per Nema/UL requirements
  • FirstSurge's balanced 600-Volt protection ratings means every primary paired conductor (line to neutral, line to ground, and neutral to ground) will knock down surge over voltages to safe levels
  • Every FirstSurge electrical AC service protector is equipped with worry free commercial class 3-stage notification; when FirstSurge wears out, its audible alarm will beep, protection status LED/s extinguish, and red service LED flashes
  • When 3-stage notification activates, you turn off FirstSurge dedicated breaker, and you contact your electrician to arrange for installation of replacement unit
  • FirstSurge can be used to surge protect any load center brand when connected to a 30A or less 2 pole circuit breaker
  • Every FirstSurge electrical AC service protector is assigned underwriters laboratories highest robustness nominal discharge current of 20kA
  • FirstSurge is designed to surge protect standard residential split phase 120/240, 60 Hz system voltage
  • FirstSurge is constructed using our commercial grade NEMA 4X enclosure allowing for indoor or outdoor installations
  • FirstSurge Surge Protective Devices (SPDs) are Type 2 and UL / cUL listed, meeting designated protection requirements
  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Whole-House Surge Protectors

Whole House Surge Protector
current product
FirstSurge Pro 140kA Whole House Surge Protection Device
FirstSurge Power 60 kA Surge Protector Bundle
BrandEatonSiemensSiemens
NameWhole House Surge ProtectorFirstSurge Pro 140kA Whole House Surge Protection DeviceFirstSurge Power 60 kA Surge Protector Bundle
Price
$11154
$19830
$29224
Ratings
(167)
(52)
(0)
View ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)
9.84
Product Height (in.)
3.94
Product Width (in.)
5.90

Details

Connection type
Panel Mount
Electrical Product Type
Secondary Surge Protection
Joules
4700
Maximum Amperage (amps)
0
Product Weight (lb.)
2.99
Returnable
180-Day

Warranty / Certifications

Certifications and Listings
UL Listed
Manufacturer Warranty
10 Year

Questions & Answers

45Questions46Answers

Would a FS140 installed on the main panel also protect a subpanel? Or, would the subpanel require its own protective device?

Asked by Charlie May 29, 2019
6
Answers

An FS140 on the main panel will provide protection for the entire electrical system. However, having several layers of protection is always the best strategy. This would mean smaller SPD's at subpanels and point-of-use surge protectors at receptacles powering sensitive equipment such as computers, microwaves, garage door openers, entertainment centers, etc.

Can this be piggybacked onto an existing 2-pole breaker (Dryer,AC), or does it require its own breaker?

Asked by georgia July 18, 2016
6
Answers

No, NEC says that you may not put more than one wire in a terminal.

Okay I'm confused do you use a 20 amp double pole breaker or 30 amp double pole breaker. Reviews below mentioned both so

Asked by Amitt July 8, 2018
5
Answers

A dedicated two pole, 20 amp breaker is what is specified in the literature that comes with this unit. It doesn't really make any difference because the cost of a 30 amp, two pole breaker is within pennies of a 20 amp two pole breaker so if you are more comfortable with a 30 amp breaker, go ahead and use one. I have installed several of these devices using the 20 amp breaker that is specified. The only thing that IS important is that the breaker is dedicated to this unit and not connected to anything else.

Can I install myself? know how to turn breakers off, but haven't rewired in the breaker box.

Asked by James September 8, 2019
5
Answers

Do not try yourself you will probably die. Much more complicated then switching off a breaker.

Must the dual pole breaker that this device is connected to be located at the top of the buss str...

Asked by Bob September 6, 2018
5
Answers

I would connect to any convenient breaker pair. If unsure, just use a volt meter between the two breaker connections and make sure you get 240 volts on the pair selected before you turn off the main breaker to do your wiring.

Question, in your video you show this being wired into two breakers both on the same L1 leg, does...

Asked by mark March 30, 2019
5
Answers

Good question, I have not seen the subject picture, but you are making correct statements. Just remember that normal sized breakers next to each other are on opposite phases because of the way the panel buses are arranged! By the way, I do not believe this product is intended for 3phase panels.

I recently lost a cooktop circuit board and an AC fan ECM to power surges, so I guess it is time ...

Asked by Arnold November 9, 2018
4
Answers

Ideally, and in order to only install one unit, you should connect this surge protector to the main electrical panel that's on the exterior of your home. I have a similar situation in my home, where my main service panel is located outside my house but I don't have any space in the main panel, to install another breaker. What I did was install two of these units to my electrical sub panels, which cost me another $250 dollars but considering that the cost of replacing my AV equipment and the major kitchen appliances could be tens of thousands of dollars, I figured it would be worth the price of another surge protector unit. If you CAN connect this unit to your main electrical panel, you may have to install it inside a weatherproof/rain tight box and connect that box to your panel in order to protect it from the weather or from damage by inadvertent contact. You don't have to install the dedicated, two pole, 20 amp breaker to which this unit is connected at the top of your panel. The breaker can be installed anywhere inside the panel.

Can the FirstSurge be mounted vertically to allow the wires to enter the box straight from the bottom?

Asked by Rod June 8, 2019
4
Answers

Yes, that is exactly how I mounted mine and it made the installation very fast and easy.

Is this unit approved for use in a commercial application? (not 3 phase)

Asked by Jim October 11, 2018
3
Answers

This unit can be used in any application that has a 120/240 volt, single phase, four wire system. You might want to contact Siemens before you purchase this device, to make sure it will be sufficient for your application needs but this device can't differentiate between a commercial or residential application as long as it is wired to the system described in my first sentence.

What is the typical cost to have this professuinally installed ?

Asked by Jarm April 27, 2016
3
Answers

It depends on your current setup, i.e., physical space and available breaker space, flush mount or not, indoor or outdoor installation, etc. You should get a quote.

FirstSurge Pro 140kA Whole House Surge Protection Device - page 2

Customer Reviews

  • 52 Customer Reviews
  • 4.9 out of 5 stars overall
96% of customers recommended.
Overall Ratings
5star-icon(47)
4star-icon(4)
3star-icon(0)
2star-icon(1)
1star-icon(0)
Sort By:
This is a nice product and will provide surge protection to my whole house. However be sure to a...
Quality :
5
Value :
5
This is a nice product and will provide surge protection to my whole house. However be sure to also order a 3/4" Frigid Chase Conduit Nipple, a 20A 2-pole breaker that matches your breaker box brand and graphite or other anti-friction material since you will need them to install this product. I had to run to Home Depot after taking delivery to get these. Before ordering check where you can install this. My panel was too close to a wall on the right side and all my punch-outs on the left side either had conduit thru them or were to too close to the 2x4 that mounted the panel so I had to mount it from the panel bottom. Make sure your panel has room for a two pole breaker or you will have to add the leads to an existing 20A 2-pole breaker.
Was this helpful?
2
0
installed this SPD myself, with no problems but don't try it if you have not worked on Power Dist...
installed this SPD myself, with no problems but don't try it if you have not worked on Power Distribution Panels. Biggest problem was finding room for a circuit breaker in my panel. Had to move some breakers around. After wiring and checking connections I flipped the new breaker on and was rewarded with two bright green LEDs. (Normal Operation)
Was this helpful?
1
0
I went with the "Pro" unit since it looked like we were border line on the map shown by Siemens. ...
I went with the "Pro" unit since it looked like we were border line on the map shown by Siemens. Also I chose to recess the unit since it was quite large and would appear intrusive in our closet. The install went fairly easy and those LED lights are bright enough to provide light. Follow the directions that come with the "Pro" and I believe you will be happy with it. I used separate 20 amp breaker and tried to minimize my wire run length, that took some breaker swapping. All in all I did the install and built the trim around the hole in the dry wall in about half a day. That was after 4 trips to Home Depot for electrical fittings :)
Was this helpful?
4
0
This item was very easy to install. Two black wires into the 20a double breaker and the white an...
This item was very easy to install. Two black wires into the 20a double breaker and the white and green into the side grounding bars. We took a surge hit in Nov16' that took out about $4k in electronics. Hope this will take care of that in the future. We also installed the phone/dsl surge and the coax surge protectors. Most of the equipment was on surge strips, but that didn't protect the stuff. I installed this with the Siemens face plate. The face plate needs to have it's hole stamped bigger. I made it work, but the mounting bolts are about an 1/8" gap behind the plate and the surge protector doesn't fit flush in the faceplate.
Was this helpful?
5
0
Works, but it's big
Quality :
5
Value :
5
Seeds Program Review
(What's this)
I've been meaning to install a whole house surge suppressor for a while now but just haven't gotten around to it. So, when I saw this come up for review I grabbed it. I'm not an electrician but I have enough experience working inside my breaker panel that I'm confident this shouldn't be a difficult install. My area of the country doesn't see a lot of devastating lightning strikes but I have had one hit close enough to my house that it blew out some of my networking equipment. It was about $400 worth of stuff that needed replacing and I'm not anxious to do it again. Nothing will stop a powerful nearby lightning strike, but hopefully this will buy me a little bit of protection, even if it only prevents surges coming from the utility's systems. This was shipped to me in a very non-descript brown cardboard box, with yellow tape wrapped around the wiring and the unit that read "120v". The manual looks like it was printed out on a laser printer, folded in half, and shoved in the box. So, I have a feeling I was sent one of their very early versions of this product. It doesn't have the glamour that most consumer products would have, a shiny box with glossy owner's manual. There are ZERO instructions on how it should be installed, so I researched the requirements of other similar Type 2 brands/models to see which were similar. It turns out they all basically install in the same way. Looking at the wiring this unit will protect up to 2 separate phases even though the label on the unit itself describes 3 phase protection. I don't see how that would be possible since it only has a ground (green), neutral (white), and 2 hot (black) wires exiting. Two hot wires to support both 120v phases that come into almost all homes. Maybe the label is used on more than one model protector? I see no reason why you couldn't use this on a single phase system as well though. Two protect two phase systems you will need at a minimum a 20 amp 2 pole circuit breaker and that breaker should be installed as close to the main breaker as possible with the wiring going to the protector kept as short as possible. One black wire goes to each connection on the breaker. In other words, don't connect both black wires to only one of the poles of the circuit breaker. Sadly, installing the new 20 amp breaker close to the main breaker won't be possible for me. All of my existing circuit breakers were installed from the top down when the house was built in 2009 and the wiring in the panel will be too short to relocate them. It looks like I will have to place the new breaker closer to the bottom of the panel which is not ideal. I used a 20 amp double pole Siemens breaker since my panel is made by Siemens and so is the surge protector. I initially thought I could mount this inside my breaker panel but now that I have it in my hands I don't think that will be possible since it is quite large. In fact, I think it is quite a bit larger than any of its competitors. I measure it out to be 8.25" wide, 3.5" deep, and 3" tall. It looks like I will need to mount this below my breaker panel. To make matters more difficult, my main breaker panel was flush mounted with the drywall in my garage so that means I am going to have to cut open some drywall in order to run a short length of electrical conduit from the panel to the surge suppressor. In the end it's probably better to have it mounted outside the panel because you can see if it is working just by looking at it, and if/when it fails the audible alarm will be easier to hear. That being said, if this were smaller it would be so much easier to install. The female threaded end accepts a 1" pipe thread and from the center of the fitting to the bottom of the unit measures 1.5". This is supposed to be a standard NEMA 4 package. Now that I have the protector installed it seems to be working pretty well. I mounted it to a piece of 1/2 plywood which in turn is mounted to the studs on either side of the breaker panel. I didn't feel comfortable just having it hang from the metal conduit or attaching it to the drywall. Lot's power can move through this thing so better to make sure it's secure. I used a couple of threaded conduit elbows and a short length of 3/4" conduit to run the wiring directly to a knockout plug on the bottom of the breaker panel. I'm not an electrician so if you're not comfortable working inside your main breaker panel I highly recommend hiring one to do it for you. You'll notice I had to sacrifice and install the breaker at the bottom of the panel. This is due to the fact that I had to mount the surge protector below the panel and because I don't think I have enough length on my existing circuit wiring to be able to slide everything down two slots. When powered on, the A and C phase indicator lights are lit up green and they are really bright. I can only assume it is working because I don't have the type of equipment needed to put a high surge through this unit. Overall, it seems really well built. I just wish it could fit in the panel an that the instructions were better.
Was this helpful?
6
0
Every Modern Home Should Have One
Quality :
5
Value :
5
Seeds Program Review
(What's this)
When I saw that the FirstSurge Pro 140kA Whole House Surge Protection Device (SPD) was available I grabbed it immediately. The modern home has so many devices that depend on electronics to operate that not having a simple whole home surge protector is like playing with fire. It's cheap insurance, and when the fact that Siemens provides a 10 year and up to $25,000 ($1500 per device) warranty is taken into consideration, it's a no brainer. One thing that was not stated in the installation directions was the recommendation to install the SPD as close to the incoming electrical lines as possible. The reason being that the incoming surge will see the SPD immediately and be safely rerouted, and as a result it would not fry anything down line. I called Siemens' Customer Support line about this omission. The gentlemen on the line knew exactly what I was talking about, however, he said that if there were no free spaces for the SPD in front of the existing breakers, that a spot toward the bottom should work fine if a surge ever occurred. Well, needless to say I made sure that the SPD was installed in the top spot so that, if a surge were to ever occur, it would be safely taken care of before it put an early end to any of my devices or appliances. Currently, the 2 green LED lights are shining brightly next to my electrical panel. Hopefully I will never need the FirstSurge Pro 140kA Whole House Surge Protection Device, but it is there just in case. I would definitely recommend it to any friend or family member.
Was this helpful?
7
0
Top quality protection for all my electronic gadgets
Quality :
5
Value :
4
Seeds Program Review
(What's this)
We don't usually get lightning here, but have lots of windstorms with downed lines, so I wanted a whole house surge suppressor to protect my many gadgets from power surges. The FirstSurge Pro FS140 is a large, heavy duty surge protection device. It has a 10 year warranty and a connected equipment warranty of $1500/item and $25,000 total. There are 3 indicator lights and an audible alarm when attention is required. The four hookup wires are 36" long 10 gauge stranded copper. I used a 3/4" conduit nipple to mount it to a knockout on the bottom of my breaker box and connected it to a dedicated 20 amp breaker mounted adjacent to the main breaker as recommended. Installation took about 15 minutes.
Was this helpful?
9
0
It arrived quickly and was easy to install. After losing...
It arrived quickly and was easy to install. After losing AC sytem components to power company power surges with expensive repairs, I now feel my AC System, Stove, Refrigerator, Washer, and Dryer are protected more than they were. In abouth 14 months, it will be saving money, rather than paying the power company to provide similar protection in monthly charges. The green lights and audible alarm also provide peace of mind.
Was this helpful?
0
0
Quick shipping. Easy to install. Now I have peace of...
Quick shipping. Easy to install. Now I have peace of mind, after losing all my appliances to a power surge. Never again!!
Was this helpful?
0
0
Was this helpful?
0
0
