Model #THDB62800HF1

Store SKU #1002236851

Titen HD 5/8 in. x 8 in. Zinc-Plated Heavy-Duty Screw Anchor

  • The Professional's Choice
  • Can install closer to the edge of concrete than expansion anchors
  • Approved for use in seismic areas
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

The Titen HD is a patented, high-strength, easy-to-install screw anchor for use in cracked and uncracked concrete, as well as uncracked masonry. The Titen HD offers low installation torque and outstanding performance. Designed and tested in dry, interior, non-corrosive environments or temporary outdoor applications, the Titen HD demonstrates industry-leading performance even in seismic conditions.
  • Qualified for static and seismic loading conditions
  • Thread design undercuts to efficiently transfer the load to the base material
  • Specialized heat-treating process creates tip hardness for better cutting without compromising the ductility
  • No special drill bit required - designed to install using standard-sized ANSI tolerance drill bits
  • Testing shows the Titen HD installs in concrete with 50% less torque than competitor anchors
  • Hex-washer head requires no separate washer, unless required by code, and provides a clean installed appearance
  • Zinc-plated carbon steel anchor can be used for temporary exterior applications
  • Removable - ideal for temporary anchoring (e.g., formwork, bracing) or applications where fixtures may need to be moved
  • Caution: Use a Titen HD screw anchor one time only - installing the anchor multiple times may result in excessive thread wear and reduce load capacity
  • Shop all Simpson Strong-Tie here.
  • California residents

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Masonry & Concrete Anchors

current product
Titen HD 5/8 in. x 8 in. Zinc-Plated Heavy-Duty Screw Anchor
1/2 in. x 7 in. Kwik Bolt 3 Long Thread Carbon Steel Expansion Anchors (2-Pack)5/8 in. x 6 in. Hex Nut Head HLC Sleeve Anchors (2-Pack)3/4 in. x 7 in. Kwik Bolt 3 Long Thread Carbon Steel Expansion Anchors (2-Pack)
BrandSimpson Strong-TieHiltiHiltiHilti
NameTiten HD 5/8 in. x 8 in. Zinc-Plated Heavy-Duty Screw Anchor1/2 in. x 7 in. Kwik Bolt 3 Long Thread Carbon Steel Expansion Anchors (2-Pack)5/8 in. x 6 in. Hex Nut Head HLC Sleeve Anchors (2-Pack)3/4 in. x 7 in. Kwik Bolt 3 Long Thread Carbon Steel Expansion Anchors (2-Pack)
Price
Ratings
(8)
(15)
(7)
(14)
Fastener Length (in.)8767
Fastener Head StyleHexHex NutHex NutHex Nut
Fastener/Connector MaterialSteelSteelSteelSteel
Package Quantity1222
Maximum Weight Capacity (lb.)0 0
Finish FamilySpecialty FinishesZincZincZinc
Anchor Diameter (in.)5/8"1/2"5/8"3/4"
Fastener TypeConcrete ScrewsWedge AnchorsSleeve AnchorsWedge Anchors
View ProductView ProductView ProductView Product

Specifications

Dimensions

Anchor Diameter (in.)
5/8"
Anchor Length (in.)
8
Fastener Length (in.)
8
Required Drill Hole Size (in.)
0.75

Details

Color Family
Steel
Fastener Head Style
Hex
Fastener Plating
Zinc
Fastener Type
Concrete Screws
Fastener/Connector Material
Steel
Fastener/Connector Material
Steel
Fastening Base Material
Brick,Cinder Block,Concrete
Features
No Additional Features
Finish
Zinc
Finish Family
Specialty Finishes
Included
No Additional Items Included
Indoor/Outdoor
Indoor/Outdoor
Interior/Exterior
Interior
Maximum Weight Capacity (lb.)
0
Measurement Standard
SAE
Package Quantity
1
Primary Use
Concrete and Masonry
Product Weight (lb.)
0.8231 lb
Returnable
90-Day

Warranty / Certifications

Manufacturer Warranty
Limited Warranty

Questions & Answers

4Questions4Answers

Can this product be used outdoors to anchor 6 x 6 post to concrete piers?

Asked by Rob April 14, 2021
1
Answer

The Titen HD is designed for use in dry, interior, non-corrosive environments or temporary outdoor applications. For extended outdoor applications, please see the Stainless-Steel Titen HD: https://www.strongtie.com/mechanicalanchors_mechanicalanchoringproducts/thdss_anchor/p/stainless-steel-titen-hd. Thank you!

What size should hole be drilled for installing the 5/8" anchor?

Asked by James September 23, 2020
1
Answer

The 5/8" Titen HD anchor requires a 5/8" diamter drill bit. Thank you!

HOW CLOSE TO The EDGE OF THE CONCRETE CAN YOU USE THESE?

Asked by RainH2o December 28, 2019
1
Answer

The minimum edge distance for the 5/8" Titen HD anchors is 1 3/4", but reductions may apply. Please visit our website for complete information or contact our technical support team for assistance - 800/999-5099. Thank you!

Available at Milwaukee St. store in Boise, ID.?

Asked by Skeeter December 21, 2017
1
Answer

Hi Skeeter, this item is currently in stock online and it may be available at your local Home Depot store as there is a listed store SKU number. Please bear in mind, we try to keep store inventory as accurate as possible, but it is best to reach out to the local store to verify quantity. To determine availability you will need to localize the item online by using your zip code. 1. Localize Homedepot.com using your zip code (My Store Location: Change) 2. Choose the store where you want to pick up the item (Make this my Store) If you do not see the store inventory for this item, it is most likely an online exclusive in your region and must be ordered online. We appreciate your business and look forward to serving you in the future. Thank you for shopping Home Depot!

Customer Reviews

  • 4.7
    out of 8 reviews
  • 100% recommend this product
Filter by:
Showing 1-8 of 8 reviews
Second story deck with landing, excellent grabbing and a very strong hold on brick siding house
Second story deck with landing, excellent grabbing and a very strong hold on brick siding house
by Jody
Massive...
Massive
by Jmk
I liked the concept of the anchor bolt but, I...
I liked the concept of the anchor bolt but, I had two that broke on me while drilling it in. I was kind of bummed about that. I guess it heated up and broke! All in all it did it’s job!
by Nick
Went in with no issues and is holding strong, way stronger of an anchor than the wedge types.
Went in with no issues and is holding strong, way stronger of an anchor than the wedge types.
by Robert
Rating provided by a verified purchaser...
Rating provided by a verified purchaser
by HomeDepotCustomer
5 Star Review
Rating provided by a verified purchaser
by Wheaton
Worked very well, in 5 day old concrete....
Worked very well, in 5 day old concrete.
by Jcqmsllc
Easy to use put red heads to shame....
Easy to use put red heads to shame.
by TheHerd
Showing 1-8 of 8 reviews
