Homeline 125 Amp 24-Space 48-Circuit Indoor Main Lug Qwik-Grip Plug-On Neutral Load Center with Ground Bar, Surge SPD
- Less wiring, clean gutter, fast installation with Plug-On Neutral
- Compatible with any Square D Homeline circuit breaker
- Ground bar, cover, and HOM250PSPD surge device included
- View More Details
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
Magic Apron Assistant is an AI virtual assistant. By proceeding, you consent to the recording and use of your information by The Home Depot (and authorized third parties). More information
Product Details
About This Product
The Square D Homeline 125 Amp 24-Space 48-Circuit Indoor Convertible Main Lugs Load Center with cover for Plug-on Neutral breakers includes a ground bar and a 50kA Plug-On Neutral Whole House Surge Protective Device. It is a compact and affordable surge suppressor designed for installation into Homeline Plug-on Neutral residential load centers and CSED's. This device reduces surges that might otherwise overwhelm plug strips and damage connected household equipment. It also provides surge suppression for important items that are not compatible with plug strips such as washers, dryers, refrigerators, stoves and lighting. This load center is UL listed for residential and commercial power distribution. It is built with a plated, aluminum bus bar that is tested and listed only for Homeline circuit breakers. Homeline load centers are designed for the value-minded contractors, remodelers, builders and homeowners. Homeline load centers are engineered for fast installation and wire savings.
Highlights
- Shop the Square D Homeline Breaker Box Collection
- Includes a fully distributed neutral bar, allowing for the installation of Homeline plug-on neutral combination arc fault breakers on any space
- Each pole space accepts full-size, tandem or quad breakers
- Ground and neutral bars accept up to (3) #10-14 equipment grounds
- Includes a PK15GTAL ground bar, a combination flush/surface cover and is convertible to main breaker load center with a QOM1 main breaker (sold separately)
- 50,000 Amp/phase maximum surge current backed by our 5-year warranty - $50,000 downstream equipment protection
- Overhead/underground feed simply by rotating the device before installing
- Single phase
- Rated 120/240 VAC and 65,000 air short circuit current rating
- Automatic flush adjusting cover requires less time to complete the job
- Designed with straight-in mains to save expensive cable and time
- Distributed split branch neutral with terminal screws backed out offering with up to 50% more terminals than UL requires increases wiring flexibility saving installation time and simplifies wiring
- Thermoplastic interior assembly is among the most rugged in the industry
- Slot/square drive screws let you use either standard flat blade screwdriver or square-head driver for positive drive and proper torque
- For protection from damage or theft on the job site, interiors can be easily removed with a single captive screw
- 2-equipment ground bars are factory-included for field mounting in 3 locations (left, right and end) letting you pick the easiest spot to wire
- Learn More About Electrical Panels Here in our Buying Guide.
- Click here for more information on Electronic Recycling Programs
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions: H 26.04 in, W 14.25 in, D 3.75 in
Dimensions
Product Depth (in.) | 3.75 in |
|---|---|
Product Height (in.) | 26.04 in |
Product Width (in.) | 14.25 in |
Details
Breaker Box Type | Subpanel |
|---|---|
Connection Type | Neutral |
Indoor/Outdoor | Indoor |
Maximum Amperage (A) | 125 A |
Mounting Type | Surface |
NEMA Configuration | NEMA 1 |
Number of Circuits | 48 |
Number of Spaces | 24 |
Product Weight (lb.) | 24.49 lb |
Returnable | 90-Day |
Series Type | Homeline |
Voltage (V) | 120/240 V |
Warranty / Certifications
Certifications and Listings | UL Listed |
|---|---|
Manufacturer Warranty | Square D warrants its single phase load centers, in a residential application, to be free from defects in material and workmanship under normal care and proper usage for a period of 10 years from the date of installation for HOMELINE load centers when used with the appropriate Square D HOMELINE branch circuit breakers. |
Questions & Answers
How do you unbond the netural bus from the case if using as sub?
You only need to don't install the green bonding screw. Without the screw, the neutral and the ground are not attached together and you can use it as a subpanel. Regards, Schneider Electric Customer Care.
With the Quick Grip style panel, how do you install larger wires for a range or dryer circuit?
It is not stated the wire size required for the range and dryer. The Qwik-Grip inserts will accept NM-B wire. There are numerous sizes dependent on postion. Please contact our support to confirm the wire range need for your dryer circuit and range. 888-778-2733 option 2-1-4 Regards, Customer Care
