Homeline 200 Amp 30-Space 60-Circuit Indoor Main Breaker Plug-On Neutral Load Center with Cover(HOM3060M200PCVP)

$198.00
Apply Now
Pay $173.00 after $25 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Less wiring, clean gutter, fast installation with Plug-On Neutral
  • Compatible with any Square D Homeline circuit breaker
  • Homeline breakers, cover, and aluminum bus bar included
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details
Install Plug-on Neutral Breakers to connect directly to the neutral bar without the pigtail.

Square D Homeline Plug-on Neutral Breaker Boxes

Install Plug-on Neutral Breakers to connect directly to the neutral bar without the pigtail to save time.

Square D Homeline Main Lug breaker Boxes can be converted to Main Breaker breaker boxes or the other way around.

Square D Breaker Boxes with Convertible Mains

Square D Homeline Main Lug breaker Boxes can be converted to Main Breaker breaker boxes or the other way around.

Square D Homeline Breaker Boxes are compatible with all Homeline Circuit Breakers

Square D Homeline Breaker Boxes are compatible with all Homeline Circuit Breakers

Compatible with Homeline 1 in. thermal magnetic, pig-tail style, and Plug-on Neutral advanced function breakers.

Save installation time and protect your home’s electrical system with Plug-on Neutral technology in our SPDs and Homeline breaker panels

Homeline Breaker Boxes compatible with Plug-on Neutral surge protective devices

Save installation time and protect your home’s electrical system with Plug-on Neutral technology in our SPDs and Homeline breaker panels. SPDs sold separately.

Compatible with the Wiser Energy Smart Home Monitor to learn about real-time home energy usage.

Install Smart Energy Management Device Wiser Energy

Compatible with the Wiser Energy Smart Home Monitor to learn about real-time home energy usage. Wiser Monitor sold separately.

Copper dipped Aluminum bus bars that are tin plated to prevent corrosion with backed-out terminal screws.

Fully distributed aluminum neutral bars

Copper dipped Aluminum bus bars that are tin plated to prevent corrosion with backed-out terminal screws.

Gray combination cover for flush or surface mount installation included with load center. Replacement covers available.

Square D Homeline Breaker Box Cover options

Gray combination cover for flush or surface mount installation included with load center. Replacement covers sold separately.

Save wire and time with Plug-On Neutral Breaker Boxes

Save wire and time with Plug-On Neutral Breaker Boxes

Square D Homeline Breaker Boxes have fully distributed split neutral bar that accept Plug-On Neutral breakers.

Time and labor saving installation with less wire

Faster installation with Plug-on Neutral

Time and labor saving installation with less wire.

No pigtails in Plug-on Neutral circuit breakers

Frees up gutter space in your breaker box

No pigtails in Plug-on Neutral circuit breakers.

Homeline accessories maximize installation flexibility to meet your electrical code needs. Contact your local utility for specific code needs.

Square D offers complete line of Homeline accessories. Sold Separately

Homeline accessories maximizes application and installation flexibility to meet your electrical code needs. Please contact your local utility for details specific to your code.

Square D offers coverage under normal care and proper usage in residential installation. Please refer to full warranty document for details.

10 year warranty

Square D offers coverage under normal care and proper usage in residential installation. Please refer to full warranty document for details.

Square D provides dedicated support anytime, anywhere.

24/7 product support

Square D provides dedicated support anytime, anywhere.

About This Product

The Square D Electric Homeline Value Pack 200 Amp 30-Space 60-Circuit Indoor Convertible Main Breaker Load Center provides safety and value to contractors, remodelers or homeowners. It's built with a plated, aluminum bus bar that's compatible with Square D Homeline circuit breakers. These breaker boxes are designed for fast installation and wire savings. This breaker is fully distributed and UL listed for residential and commercial power distribution.

Highlights

  • Learn about general NEC 2020 updates. Contact your local building inspector for adoptions and details.
  • Includes a fully distributed neutral bar, allowing for the installation of Homeline plug-on neutral combination arc fault breakers on any space
  • Each pole space is compatible with a Square D Homeline full-size, tandem or quad breakers
  • Ground and neutral bars accept up to (3) #10-14 equipment grounds
  • Includes (3) HOM120 Homeline 20 Amp single-pole circuit breakers, (2) HOM230 Homeline 30 Amp double-pole circuit breakers and a combination flush/surface cover
  • Accommodates plug-on secondary surge arrestor (sold separately)
  • Overhead/underground feed simply by rotating the device before installing
  • Single phase, Indoor Main Breaker Homeline Breaker Box
  • Rated 120/240 VAC and 22,000 AIR short circuit current rating
  • Automatic flush adjusting cover requires less time to complete the job
  • Designed with straight-in mains to save expensive cable and time
  • Distributed split branch neutral with terminal screws backed out offering up to 50% more terminals than UL requires; increases wiring flexibility, saves installation time and simplifies wiring
  • Thermoplastic interior assembly is among the most rugged in the industry
  • Slot/square drive screws let you use either standard flat blade screwdriver or square-head driver for positive drive and proper torque
  • For protection from damage or theft on the job site, interiors can be easily removed with a single captive screw
  • 3-ground bar mounting locations (left, right and end) let you pick the easiest spot to wire
  • Learn More About Electrical Panels Here in our Buying Guide.
  • Installation Guide
  • Click here for more information on Electronic Recycling Programs
  • Return Policy
  • California residents
     see Prop 65 WARNINGS

Product Information

Internet # 204836369

Model # HOM3060M200PCVP

Store SKU # 1000040129

Store SO SKU #1000113540

Specifications

Dimensions: H 33.78 in, W 14.25 in, D 3.75 in

Dimensions

Load center depth (in.)

3.75

Load center height (in.)

33.78

Load center width (in.)

14.25

Product Depth (in.)

3.75 in

Product Height (in.)

33.78 in

Product Width (in.)

14.25 in

Details

Breaker Box Type

Main Breaker

Connection Type

Neutral

Electrical Product Type

Load Center and Breaker Kit

Included

Circuit Breaker, Cover

Indoor/Outdoor

Indoor

Load Center Mounting Type

Flush, Surface

Load Center Type

Main Breaker

Maximum Amperage (A)

200 A

Mounting Type

Flush, Surface

NEMA Configuration

NEMA 1

NEMA Configuration Receptacle

No Receptacle

Number of Circuits

60

Number of Pieces

6

Number of Spaces

30

Phase Type

1 Phase

Product Weight (lb.)

34.83 lb

Returnable

90-Day

Series Type

Homeline

Voltage (V)

120/240 V

Warranty / Certifications

Certifications and Listings

UL Listed

Manufacturer Warranty

Square D warrants its single phase load centers, in a residential application, to be free from defects in material and workmanship under normal care and proper usage for a period of 10 years from the date of installation for HOMELINE load centers when used with the appropriate Square D HOMELINE branch circuit breakers.

Questions & Answers

372Questions
caret
Q:Does it come with main breaker only or with so.e 20 and 30 a.p as well?
by|Apr 14, 2024
1 Answer
Answer This Question

A:  Tristen, Yes, the HOM2040M200PCVP comes with a QOM2 main breaker included, QOM2200VH. Warm regards. Schneider Electric Customer Care

by|Apr 15, 2024
    caret
    Q:Does this panel come equipped with the main breaker or does this need to be purchased separately?
    by|Apr 8, 2024
    1 Answer
    Answer This Question

    A:  ChrisH, Yes, the HOM2448M100PCVP comes with a QOM1 main breaker included, QOM100VH. Warm regards. Schneider Electric Customer Care

    by|Apr 12, 2024
      caret
      Q:Will QO brakes fit this panel
      by|Apr 1, 2024
      1 Answer
      Answer This Question

      A:  Dale, Unfortunately no, the QO can only be used in QO Load Centers, will not fit in Homeline Load Centers. Warm regards. Schneider Electric Customer Care

      by|Apr 8, 2024
        caret
        Q:Will it except tandem breakers
        by|Mar 21, 2024
        1 Answer
        Answer This Question

        A:  Hi, Yes, the HOM2448M100PCVP can handle up to 24 tandem breakers. Warm regards. Schneider Electric Customer Care

        by|Apr 8, 2024
