Internet #100202111

Model #QO2175SB

Store SKU #290076

QO 22.5 kA 2-Pole Surgebreaker Surge Protective Device

  • 22.5 kA surge current capacity for QO electrical panels
  • 3 year/$10,000 connected equipment warranty
  • Requires 2 spaces in Square D QO electrical panels
  • See More Details

Frequently Bought Together

+
+
Price:
$6146

Product Overview

QO2175SB requires 2 spaces in any Square D QO load center.

Installation flexibility

QO2175SB Requires 2 spaces in any Square D QO load center.

Surge protective device provides protection against surges that come from inside or outside the home.

Stay protected 24/7

Damaging power surges happen regularly. These surges can shorten the life or even destroy electronics or appliances.

3 year, $10,000 connected equipment coverage warranty provided by Square D.

Peace of mind from the Square D brand you can trust

3 year, $10,000 connected equipment coverage warranty provided by Square D.

This tells you the power surge amp this unit can handle, the higher the better.

22.5 kA surge current capacity - 22,500 amp protection

This Surge Protective Device can handle 22,500 amp electric current capacity

Whole House surge protection compatible with Square D QO Load Centers

Whole house surge protection

Protect your electronics & appliances against electrical surges

Keeps your home protected from all surge sources, all the time

80% of power surges are internally generated

Protects against surges that are either externally generated (from weather or utilities) or internally generated from devices inside the home.

Visual confirmation the Surge Protection Device (SPD) is actively protecting your home

LED Indicator lights

Visual confirmation the Surge Protective Device (SPD) is actively protecting your home

Fits inside your existing load center, same size as a 2-pole breaker.

Compact Design

Fits inside your existing Square D QO load center, same size as a 2-pole breaker.

Protect your home without breaking the bank

Affordable

Protect your home without breaking the bank

Square D Quality Performance

Square D Quality Performance

Internal components named MOVs act like magnets and protect against excess voltage/ amps.

Square D provides dedicated support anytime, anywhere.

24/7 product support

Square D provides dedicated support anytime, anywhere.

Ready to install right out of the box, no assembly required

Ready to install

No product assembly required. Just plug in & terminate neutral wire.

Know that your home is protected and NEC 2020 Code compliant.

NEC 2020 compliant

Know that your home is protected and NEC 2020 Code compliant.

The QO Surgebreaker Surge Protective Device is designed as a quick plug-on unit is compatible with Square D QO load centers and CSED devices. The SPD requires two pole spaces. This unit has 22,500 amp maximum surge capacity and has a 150 VAC line-to-ground maximum providing protection from electrical surges.

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Whole-House Surge Protectors

current product
QO 22.5 kA 2-Pole Surgebreaker Surge Protective Device
Homeline 50 kA Plug-On Neutral Whole House Surge Protective Device40 kA 3-Phase Panel Mounted Delta Power Systems Surge Protective DeviceWhole House Surge Protector
BrandSquare DSquare DSquare DEaton
NameQO 22.5 kA 2-Pole Surgebreaker Surge Protective DeviceHomeline 50 kA Plug-On Neutral Whole House Surge Protective Device40 kA 3-Phase Panel Mounted Delta Power Systems Surge Protective DeviceWhole House Surge Protector
Price
$6146
$7633
$11034
$11154
Ratings
(93)
(54)
(4)
(170)
View ProductView ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)
2.6
Product Height (in.)
3.7
Product Width (in.)
1.5

Details

Connection type
Breaker
Electrical Product Type
Whole House Surge Protectors
Joules
930
Maximum Amperage (amps)
22500
Product Weight (lb.)
.54
Returnable
180-Day

Warranty / Certifications

Certifications and Listings
ANSI Certified,CSA Listed,UL Listed
Manufacturer Warranty
Square D warrants its QO Surge Breaker to be free from defects in material and workmanship under normal care and proper usage in a residential installation, for three years.

Questions & Answers

40Questions46Answers

how do i know where in my panel to install this device? does it matter, or just choose an empty ...

Asked by DA July 30, 2019
6
Answers

you can install the surge protector breaker anywhere in your panel so long the panel is a square D QO panel and please hook it up correctly .

how often should these be replaced?

Asked by DA July 30, 2019
5
Answers

When the green “its operating fine” led stops glowing. Or it gets hit by lightning, in which case the little green light will also likely cease to glow.

Will the SQUARE D QO 22.5 kA 2-Pole Surgebreaker Surge Protective Device fit in a GE service panel

Asked by charles February 4, 2019
5
Answers

ProbBLY NOT

Will this device fit in a GE Panel?

Asked by Tom February 4, 2019
7
Answers

No. Only fits Square D QO panels.

double pole sq d surge protector in stock in the houston area

Asked by jim April 13, 2018
1
Answer

Since I am in no way anywhere near Houston I would have to go on line or call a Houston area store to find the answer to this question. Being a firm believer in cutting out the middle man I would suggest that "jim" perhaps could find a Houston area store to ask this question of. Go to the source as it were. Good luck!

what stores in the Houston area have this in stock qo2175sb

Asked by jim April 13, 2018
1
Answer

I would check on-line first on the store's in your area, and then call the store before going. Also on a Square D box there are 2 different panels, this one did fit my panel you need to get the information on the panel.

If my Surgebreaker gets a strike will the other circuit still be live or do I need to replace the...

Asked by Kit January 30, 2018
6
Answers

That's bit of loaded question. Lightning strikes can vary in "intensity"/"strength" based on numerous factors. The amount of energy a nearby strike has will have complete influence on what happens in your home's load center and downstream electrical devices. That said, this item is an excellent, fast install device that offers very good surge suppression. By the very nature (pun, i suppose) of lightning, there's no guarantee that various breakers in the panel won't also trip resulting from a strike, nor can any manufacturer promise that nothing can ever be damaged. The effect of a lightning strike can be mild or catastrophic, but this will offer essential protection to greatly increase your odds of equipment survival. As others have suggested, the green LED on the face is supposed to indicate that the surge device is still healthy and ready to offer continued protection. Reminder, "surges" and "spikes" don't just happen from lightning, there are many power disturbances that can happen from utility company routine operations or mishaps. I'm a 28 year veteran in electrical contracting, and have seen a lot.

I have two questions. Before installing the device should the breaker for the entire house be shut off ?

Asked by JT January 28, 2018
5
Answers

When accessing any enclosure where live electrical parts are exposed and when you will be performing a procedure that requires you to install a part onto the live surface, you should first de-energize the exposed live parts. Yes, turn off the house main breaker or disconnect before opening the panel. If the panel that the part is going into is the main service panel for the building then it is OK to run the white wire to the ground buss since the ground and neutral busses are common. If the panel is a sub panel then the white wire goes to the neutral buss.

Call me lazy, but I'd like to be able to verify the green light is lit without opening the panel....

Asked by Connectionstools September 24, 2017
5
Answers

You should be able to see the green light without drilling any holes. Try knocking the tab out of the panel cover where the breaker is located.

To make room at the entrance (top) side of the panel for the surge breaker, I'll have to relocate...

Asked by Connectionstools September 24, 2017
5
Answers

Its fine. Consult/hire an electrician so you don't die!

QO 22.5 kA 2-Pole Surgebreaker Surge Protective Device - page 2

Customer Reviews

  • 4.7
    out of 94 reviews
  • 97% recommend this product
5star-icon73
4star-icon17
3star-icon0
2star-icon2
1star-icon2
Filter by:
Showing 1-10 of 94 reviews
Pruchased 2 since I have 2 panels. Breakers arrived when expected. easy to install. So easy I w...
Pruchased 2 since I have 2 panels. Breakers arrived when expected. easy to install. So easy I went ahead a installed a couple more for a friend. took 10-15 minutes to complete 2 panels. I won't know how well they work until the next lightning strike. Last lightning strike cost me several thousand dollars. Hopefully these will help.
by psychdoc
Pretty sure it saved us from a lot of damage
South Florida. Had lightning strike my power pole this afternoon. So far I've discovered it blew out a power supply for my modem and an LED light fixture in the garage. I installed one of these SPDs last summer. It's cheap. It's easy to install if you have a little knowledge on residential electrical hardware. As title suggests, I think it saved us from a lot more damage. There's no way to know for sure, but I'm pretty confident it's true. Best part - the SPD is still alive in my panel.
by Mark
I installed one of these in my load center and another in my in-laws. It's easy to install and pr...
I installed one of these in my load center and another in my in-laws. It's easy to install and provides surge protection for your entire home. Just make sure you install it in the first two breaker slots so the surge is diverted to ground before it reaches any of the other circuits.
by Max
Easy to Install
Seems to work (judging by the light). It was easy to install.
by Kyle
1 person found this helpful
Surge breaker protects major appliances
Provide surge protection from electrical spikes for major appliances by installing a surge breaker in your Square D electrical panel.
by KayakNW
5 people found this helpful
good product
Looked around for this for quite a while. Easy installation
by Rina
2 people found this helpful
Simple - Peace of Mind
Very easy to install. If you are comfortable installing a breaker, you can easily install this whole house surge protector. It took about 15 minutes to install. I had to move two breakers down the panel so that it could be as close to ground as possible. Given the number of computers and electronic appliances (fridge, stove, microwave, water heater, dishwasher, furnace) installing a whole house surge protector is a lot cheaper than replacing appliances or having them repaired. (Note, I still have my surge suppressor strips in place ... just in case.)
by n8dgr8t
12 people found this helpful
Very easy to install
A surge protector was suggested by the furnace repair guy.I contacted Wi. Public Service for information. This one meets Wi. code. It quickly snaps in and one wire to ground. Install it as the top breaker and keep the pig tail short as possible. Now my house is protected. I also use surge strips as recommended for more sensitive electrinics
by AllouezDIYer
12 people found this helpful
by ERIC
It was easy to install. I replaced an electric range in the house with a natural gas range then ...
It was easy to install. I replaced an electric range in the house with a natural gas range then removed the electric range double pole breaker and replaced it with this, often called a "whole house surge protector"
by Ted
