Model # WSS30VN

Store SKU # 1003818286

Upgraded 1/2 HP Combination Battery Backup System

$514.59
Apply Now
Pay $464.59 after $50 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
  • Upgraded WSS30V. Completely pre-assembled and drop in ready
  • Primary pump float switch tested to 1 million cycles
  • Assembled in the US, performance that lasts for years
  • View More Details
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy

Product Details

About This Product

The Wayne 1/2 HP and 12-Volt Upgraded WSS30V includes an all new back-up pump with an even more rugged construction. Drop in ready and easy install within about 15 minutes. The WSS30V provides additional protection and peace of mind when the power is out. Including an audible alarm, rest assured that you'll be notified as soon as the back up pump on the WSS30V turns on. Battery Sold Separately.

Highlights

  • New Wayne WSS30V combination system includes an upgraded epoxy-steel body and cast iron base back up pump, no more plastic
  • 1/2 HP primary pump moves up to 5100 GPH at 0 in. of head
  • Upgraded 12V DC back up pump moves up to 2700 GPH at 0 feet of head
  • Protects your basement with hours of pump power when the electricity goes out
  • Primary pump delivers unsurpassed protection, the switch is tested 1 million times, up to 10x more than competitors
  • Assembled in the USA, performance that lasts for years
  • Easy install in about 15 minutes
  • Wayne WSB1275 75 AMP hour battery recommended
  • Minimum recommendations: 15 in. tapered pit, or 16 in. with no taper or draft, base of pump measures 14.875 in. from the widest point across
  • Battery Sold Separately
  • Click here for more information on Electronic Recycling Programs
  • Return Policy
  • California residents
     see Prop 65 WARNINGS

Product Information

Internet # 307352334

Model # WSS30VN

Store SKU # 1003818286

Additional Resources

Shop All Wayne

Specifications

Dimensions: H 14 in, W 18.25 in, D 23.5 in

Dimensions

Product Depth (in.)

23.5 in

Product Height (in.)

14 in

Product Width (in.)

18.25 in

Details

Amperage (A)

75 A

Battery Life (hours)

6 hr

Battery Type Required

12-volt, Battery Not Included

Discharge Flow @ 0 ft. (gallons/hour)

5100

Discharge Flow @ 0 ft. (gallons/min)

85

Discharge Flow @ 10 ft. (gallons/hour)

3840

Discharge Flow @ 10 ft. (gallons/min)

64

Housing Material

Steel

Impeller Material

Thermoplastic

Included

Control Box

Number of Batteries Required

1

Pack Size

1

Product Weight (lb.)

30 lb

Returnable

90-Day

Voltage

120v, 12v

Warranty / Certifications

Certifications and Listings

No Certifications or Listings

Manufacturer Warranty

3 years

Questions & Answers

80Questions
caret
Q:Does the white coupling have to be glued to the grey Y discharge pipe? If so, with just pvc primer and glue? Thanks
by|Apr 4, 2024
1 Answer
Answer This Question

A:  They Y pipe does not need to be glued in. There should be two sets screws to secure the pipe to the coupler.

by|Apr 8, 2024
    caret
    Q:What is the warranty for this unit
    by|Mar 31, 2024
    1 Answer
    Answer This Question

    A:  Warranties are for manufacturing defects. The warranty for this pump is three years from the date of the purchase.

    by|Apr 3, 2024
      caret
      Q:I seen a question answered. That this has to be 12 inches below the tile drain. I’m guessing that’s the 4 inch line coming in. Mine is 9 inches to the bottom of the well to the bottom of this line. So before I buy this. Just want to ask. This won’t work?
      by|Mar 6, 2024
      1 Answer
      Answer This Question

      A:  It may be worth a call to a plumber to come take a look at your set up and give you their expert opinion. Different municipalities have different rules. Generally speaking, you never want your incoming drain tile to start back filling before you pump comes on.

      by|Mar 8, 2024
        caret
        Q:What size pit is required for this system?
        by|Feb 24, 2024
        1 Answer
        Answer This Question

        A:  It is recommended that your sump basin be 16" in diameter or larger. You'll need at least 12" below your inlet tile drain.

        by|Feb 26, 2024
          Showing 1-4 of 80

          Customer Reviews

          4.8 out of 5

          • 4.8 out of 182 reviews
          • 97% recommend this product
          Filter by:
          Showing 1-10 of 182 reviews
          Peace of Mind in one complete package
          I did a lot of research before choosing this system. I selected the Wayne system because the pumps seem to be solidly built and the package appears to be well designed. The installation of the pumps and the setup of the battery backup system was not difficult. I tested both pumps and they both do an effective job of removing the water from my sump. Only issue is that the system is very large and it just barely fit into my sump. So make sure your sump basin is large enough to accommodate it.
          by
            • Recommended
            Solid. This thing is a tank, most other battery back up pumps (including the one this replaced) a...
            Solid. This thing is a tank, most other battery back up pumps (including the one this replaced) are pretty dinky. Too bad it doesn't come with a battery but this way it allows you to pick exactly what you want. I went with a maintenance free style. Not sure if the description states but it also comes with an in line check valve. Also on crock size requirements: I have a tapered standard crock, 22in deep, 18in at the top and 15in at the bottomt and this fits with a little room to spare on the sides.
            by
            • Verified Purchase
            • Recommended
            2 found this review helpful
            Makes me feel secure. Works well. Easy install.Be sure you turn both off before doing any adjustm...
            Makes me feel secure. Works well. Easy install.Be sure you turn both off before doing any adjustments. Just unplugging can create a geyser. New learning curve. Lol
            by
            • Verified Purchase
            • Recommended
            3 found this review helpful
            It took less than 1 hour to install. Only problem was Watchdog battery did not properly fit in th...
            It took less than 1 hour to install. Only problem was Watchdog battery did not properly fit in the Wayne Case. Should have said you needed a Wayne battery but salesman said any battery would fit. Other than that it works like a charm
            by
            • Verified Purchase
            • Recommended
            3 found this review helpful
            Product was shipped directly to house and came a day earlier than expected. Product was easy to i...
            Product was shipped directly to house and came a day earlier than expected. Product was easy to install just needed to buy a rubber pipe connector to put the two pvc pipes together then 10 minutes later it was up and running. Product is of excellent quality. The operation of these pumps is way quieter than my old one.
            by
            • Verified Purchase
            • Recommended
            3 found this review helpful
            The Wayne WSS30VN - a simple & easy replacement for my 25 y.o. pump with a complete backup system...
            The Wayne WSS30VN - a simple & easy replacement for my 25 y.o. pump with a complete backup system. Although my old pump still worked after 25 years of hard use, it started to regularly trip the GFCI. So I decided to look for a system that combined a main AC sump pump and DC battery-backup pump. After a full day of research, reading reviews and comparing prices, I settled on the Wayne WSS30VN. As a last step in my decision process, I called the company to gauge Wayne's customer service response - I was favorably impressed. The call was answered quickly by Bob (great support person), and we went over a list of questions I had regarding the operation of the float valves, back-up electronics, and some modifications I planned on making to the discharge pipe to the foundation exterior. All my questions were satisfactorily and completely answered, and Bob made sure I was fully comfortable with all phases of the installation process. I ordered the unit from Home Depot, and the pump arrived by FedEx only two days after I placed the order. The system is as rugged and compact as it appears in the pictures, and, for the most part, really was a "plug-and-play" "drop-in" replacement. (Note that this assembly requires a sump basin with at least a 15" diameter at the base.) Because the main pump (AC power) float switch is not shrouded, when placing the unit in the sump basin, care must be taken to ensure that the float is at least an inch from the side of the basin so it can operate freely. Also, the float must not be directly under the flow of water from any of the water inlets. After slowly rotating the system within the basin, I found an acceptable position, but it was clear I would need to slightly alter the position of the existing discharge pipe to accommodate the location of the factory plumbing. I took that need as an opportunity to add, modify and reorganize several other components (something I had been "meaning to do" for years.) Although each of the two pumps came from the factory with check valves, I decided to add a "klunkless" check valve (HD 541996) and quarter-turn ball valve (HD 784923) above the pump. To add vibration isolation and wiggle-room for pump torque, I connected the lateral PVC pipe through with a 1½" flexible rubber 90 ̊ coupling. I also added a 1½" PVC slip union (HD 242935) to make it easier to remove the pump from the basin for maintenance. Once that was done, I poured several gallons of water into the basin and plugged the main pump into the GFCI outlet - it worked perfectly - and almost silently. Within seconds the water was pumped out and the unit shut itself off. I then installed the backup battery (separate purchase). The one I chose had the highest amperage rating I could find in a maintenance-free, Sealed Lead Acid (SLA), Absorbent Glass Mat (AGM) battery that would fit within the battery case provided with the Wayne system (group 27-frame size) - the Powersonic PS-121000U 12 Volt, 100 AH. After making sure that the battery was fully charged, I unplugged the main pump and battery charger (which sounded a brief audible alarm), and filled the basin. As soon as the water level rose a little over the DC pump's float switch, the backup pump fired up (again, with a brief alarm) and emptied the basin almost as quickly as the main pump had. Because the position of the outlet pipe had to change, and in order to permit the basin cover to be put in place (which it hadn't been for years), I decided to also reorient 4 discharge pipes that emptied into the sump basin (2 AC condensate drains, and the hot water heater drip pan and pressure relief valve outlet). As a final precaution, I also added a water bug water sensor to my house alarm system and placed it on the floor adjacent to the sump basin. Project done! So far. my choice of the Wayne WSS30VN has proven to be an excellent decision. As of December 15th 2018, the Northern Virginia area had experienced the highest rainfall totals ever recorded, beating the 1889 total of 61.33 inches. In the last few weeks of 2018, this system has been put to the test, with the pump cycling 1-2 times a minute for days on end. It is easily up to the task! The only "Cons" I can offer are minor: - The battery charger wall-wart should come with a longer cable. Since it is recommended that this charger NOT be plugged into the same GFCI outlet as the main pump, in my opinion the charger cable should be at least 10-12 feet long. Currently I have temporarily plugged the charger into an extension cord, but plan to have another outlet installed soon (off the one in the picture that faces another room). - Also, this charger is fairly heavy to have hanging simply by the friction of the AC prongs. It could use a bracket, maybe one that uses the center screw in the duplex outlet cover.
            by
            • Verified Purchase
            • Recommended
            43 found this review helpful
            The pumps come pre-assembled which is a time saver. Added a short piece of 1.5” PVC pipe so the check valve would be above the sump pump cover. Installation was quick, cleaned bottom of pit and put a concrete stepping paver in it for the pump to set on. I wanted to purchase the Wayne Maintenance Free battery they recommend but decided to purchase the watchdog battery (BW-27AGM) instead. The battery box has the controller built into it. The main pump work great and is quiet, I unplugged the main pump to simulate a power failure. Poured a couple of buckets of water into the pit until the back up pump kicked on. It pumped all the water out pretty quick and quietly, I would recommend.
            by
            • Recommended
            5 found this review helpful
            This is a very rugged, well made system. I've installed these types of back up pumps before with...
            This is a very rugged, well made system. I've installed these types of back up pumps before with other brands but this one seems to be of much better quality. It does not come with a battery, even though the box states that it is a complete system. It also requires a minimum 15 inch wide sump pit because the two pumps are side by side and not piggy backed. A lot of older pits are only 12" wide, so measure before you buy. Another nice feature is that the GPH pump rate of the battery back up is almost as powerful as the main pump.
            by
            • Recommended
            7 found this review helpful
            Excellent product. Installation was very simple. It is extremely quiet! Can not hear the pump ...
            Excellent product. Installation was very simple. It is extremely quiet! Can not hear the pump only the water traveling though the PVC pipe and out. I had to call the Wayne tech support because the battery backup pump connector had broke during shipping. They were easy to get a hold of, very knowledgeable and got the part out to me right away.
            by
            • Verified Purchase
            • Recommended
            3 found this review helpful
            This sump pump & back up sump pump all built into one drop in unit is exactly what I’ve been look...
            This sump pump & back up sump pump all built into one drop in unit is exactly what I’ve been looking for. I was looking into backup sump pumps for when the power goes out, and my main pump was showing it’s age. Wayne provides a 3 year warranty on this combination unit. Everything appeared to of good quality. Both the main pump and the backup are extremely quiet. Assembly was easy. It fit exactly where my old sump pump was. The only thing I had to purchase was the battery, 1 1/2 in. PVC pipe, and PVC primer and cement. I chose the basement watchdog BW-27AGM over the recommended battery because of better reviews, same amp hours, and 65$ cheaper. It fits in the provided battery case great and gives you a space to curl up some of the access cords.
            by
            • Recommended
            11 found this review helpful
