Internet #204799158

Model #Y2-5

1 in. x 3/4 in. NPT x MPT 1-1/4 in. Galvanized Steel Pipe x 5 ft. Bury Y2 Auto Drain Backflow Protected Yard Hydrant

Questions & Answers (1)
  • Flows immediately even in sub-zero conditions
  • Shuts off even when foreign particles are in the water line
  • Sets same flow each time or can lock against accidental opening
  • See More Details

Product Overview

The Woodford Model Y2 (Orange Head) 1 in. NPT variable-flow yard hydrant is immediate-flowing, even in sub-zero conditions, and is made in the USA. Includes a Nidel Model 50HF double-check backflow preventer. The adjustable linkage provides easy and positive adjustment of the lever lock tension. A rod guide eliminates side pull on the rod, reducing wear on the packing, packing nut and the stem. The one piece variable-flow plunger and the large cushion type seal for long life, assuring shut-off, even when foreign particles are present in the water line. The flow finder and lock automatically sets the same flow each time or can be locked against accidental opening. And the Y2 automatically drains when shut-off.
  • 5 ft. bury - 96-1/2 in. overall length of hydrant
  • This model Y2 yard hydrant features adjustable linkage which allows for fine adjustments of the handle
  • Woodford has manufactured the IOWA hydrant for over 50 years
  • ASSE 1052 Nidel Model 50HF high-flow double-check backflow preventer
  • Immediate-flowing even in sub-zero temperatures
  • Rod guide reduces wear on packing, packing nut and brass stem internal parts
  • Can be automatically set to obtain the same water flow every time
  • 1-piece variable-flow plunger assures shut-off, even when foreign particles are present in the water line
  • Long-life graphite packing
  • Durable hot-dipped galvanized pipe casing and operating pipe stem
  • Repairs can be made from the top of the hydrant; no need to tear out the hydrant from the ground
  • Automatically drains when shut-off
  • Made in the USA
  • Made in the USA
  • California residents

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Yard Hydrants

3/4 in. NPT x Female 1 in. Galvanized Pipe x 4 ft. Bury W34 Freezeless Yard Hydrant
current product
1 in. x 3/4 in. NPT x MPT 1-1/4 in. Galvanized Steel Pipe x 5 ft. Bury Y2 Auto Drain Backflow Protected Yard Hydrant
Model H3 - Heated Sanitary Yard Hydrant - C12Model H3 - Heated Sanitary Yard Hydrant - C25
BrandWoodfordWoodfordWoodfordWoodford
Name3/4 in. NPT x Female 1 in. Galvanized Pipe x 4 ft. Bury W34 Freezeless Yard Hydrant1 in. x 3/4 in. NPT x MPT 1-1/4 in. Galvanized Steel Pipe x 5 ft. Bury Y2 Auto Drain Backflow Protected Yard HydrantModel H3 - Heated Sanitary Yard Hydrant - C12Model H3 - Heated Sanitary Yard Hydrant - C25
Price
Ratings
(1)
(0)
(1)
(0)
ConnectionFemale Pipe ThreadFemale Pipe ThreadFemale Pipe ThreadFemale Pipe Thread
ApplicationNon-Potable WaterNon-Potable WaterNon-Potable WaterNon-Potable Water
Maximum Pressure (psi)125125125125
Compatible Pipe MaterialBrassBrassBrassBrass
FeaturesNo Additional Special FeaturesNo Additional Special FeaturesNo Additional Special FeaturesNo Additional Special Features
MaterialGalvanized SteelGalvanized SteelGalvanized SteelGalvanized Steel
Indoor/OutdoorOutdoorOutdoorOutdoorOutdoor
Maximum Working Temperature (F)120120120120
Valve TypeYard HydrantYard HydrantYard HydrantYard Hydrant
View ProductView ProductView ProductView Product

Specifications

Dimensions

Inlet Diameter (In.)
3/4
Outlet Diameter (In.)
3/4
Product Height (ft.)
5
Product Height (in.)
84.5
Product Length (in.)
84.5
Product Width (in.)
10

Details

Application
Non-Potable Water
Compatible Pipe Material
Brass
Connection
Female Pipe Thread
Features
No Additional Special Features
Indoor/Outdoor
Outdoor
Material
Galvanized Steel
Maximum Pressure (psi)
125
Maximum Working Temperature (F)
120
Pack Size
1
Product Weight (lb.)
26
Returnable
90-Day
Valve Type
Yard Hydrant

Warranty / Certifications

Manufacturer Warranty
All goods are sold with a limited warranty for one year against defects in material and workmanship.

Questions & Answers

1Questions1Answers

I have 160 psi from city Walter, will this handle that much water pressure

Asked by Ron November 10, 2019
1
Answer

Woodford hydrants are rated and tested up to @ 125 PSI.
