FOAMULAR 150 2 in. x 4 ft. x 8 ft. R-10 Scored Squared Edge Rigid Foam Board Insulation Sheathing

  • Saves energy and resists moisture with limited lifetime warranty
  • Scored edge easily snaps into smaller boards for best fit
  • Strong, lightweight pink foam panels don't require special tools
  • See More Details

Product Overview

Home with pink outline and Owens Corning logo

A Home is a Fortress

It keeps comfort and safety in - and the other stuff out. Help create the year-round protection every home deserves with proven solutions that work where and when you need them most.

close up of Owens Corning Foamular with water beads

Owens Corning FOAMULAR XPS

FOAMULAR is a rigid insulation board made of extruded polystyrene. XPS for short. Compared to EPS products, FOAMULAR XPS has 25% more insulating power and is 10 times more water resistant.

Cutaway image of a house with Foamular installed in different locations

Choose Above- and Below-Grade Protection

FOAMULAR provides continuous insulating power around the entire home from the foundation to the roofline and all kinds of spaces in between.

man installing fiberglas insulation  over Foamular

Insulating Basement Walls

FOAMULAR is the easy-to-install insulating solution for basement walls. Get added comfort with PINK Fiberglas insulation and finish with drywall board.

man installing Foamular in exterior foundation application

Insulating Foundation Walls

FOAMULAR is ideal for insulating exterior foundation walls. Extremely durable, it can withstand up to 15-25 psi and resists common acid soils and decay.

man installing siding over Foamular

Insulating Under Exterior Siding

FOAMULAR provides a higher R-value per inch than other materials commonly used for exterior wall sheathing.

man installing Foamular fanfold insulation

Also Available in Fanfold

FOAMULAR Fanfold is generally intended for use as a backer board for residing applications and comes in 50-foot sections for a faster install.

icon for moisture resistance

Superior Moisture Resistance

Virtually impervious to moisture. FOAMULAR has up to 10X more resistance to water than EPS insulation.

icon for compressive strength

Durable, Yet Flexible

A wide range of compressive strengths –up to 100 psi – to handle heavy loads.

icon for easy to cut

Easy to Cut, Form and Fit

Easy to handle, score, cut and install; no special tools needed.

icon for insulation performance

Outstanding Insulating Properties

High, stable R-value (5 per inch of product thickness) - more than wood fiber, plywood or 1/2” gypsum board.

icon for sustainability

Sustainable

Foamular is certified to meet indoor air quality standards under the stringent GREENGUARD Gold Certification Program.

icon for guarantee

Lifetime Guarantee

The only XPS with a limited lifetime warranty that guarantees a minimum 90% of R-value for the life of the product.

FOAMULAR Extruded Polystyrene (XPS) Rigid Foam Insulation offers a comprehensive line of products in a wide choice of sizes, thicknesses and edges with a Lifetime Limited Warranty for the life of the home or building. The products are easy to handle, score, cut and install & no special tools are needed. Products can be used on wood, steel framing or concrete walls. FOAMULAR XPS resists moisture and retains R-value even after exposure to standing water and wet soil. Only XPS foam to be GREENGUARD Gold Certified and the first XPS foam certified by Scientific Certification Systems (SCS) to contain a minimum of 20 percent recycled content.
  • Dimensions: 2 in. x 4 ft. x 8 ft.
  • Application: Exterior sheathing & interior basement walls
  • Designed to resist moisture and helps to block mildew
  • Has a higher R-value than wood fiber, plywood or 1/2 in. gypsum board products
  • Click here to shop Loctite foamboard adhesive
  • FOAMULAR 150 and 250 are available in various thicknesses and R-values, the difference is the compressive strength. FOAMULAR 150 has a compressive strength of 15 psi and FOAMULAR 250 is 25 psi
  • FOAMULAR is not rated for STC (sound transmission) and does not have any soundproofing properties. Owens Corning fiberglass batts and rolls are great options for acoustic applications.
  • When using FOAMULAR or any low perm insulation, always verify the moisture vapor flow and dew point characteristics of the wall system.  Please check your local building codes for vapor retarder/barrier information.
  • If being used in an interior construction application, painting the FOAMULAR is not recommended as FOAMULAR cannot be left exposed and will need to be covered by a 15 minute thermal barrier such as drywall.
  • If being used for crafts, acrylic or latex based paints can be used with FOAMULAR products.
  • If you’re looking to insulate your garage door, Owens Corning Garage Door Insulation Kit is an easy, fast and affordable way to keep your garage warm in winter and cool in the summer.
  • If you’re looking to ventilate your attic rafters, Owens Corning Raft-R-Mate is a XPS foam vent designed to assure unrestricted airflow from the soffit to the ridge vent.
  • FOAMULAR is available in two edge configurations:
  • Square Edge – designed to fit flush next to adjoining boards
  • Scored Square Edge - comes with 3 factory scores, so that you can take a 4’ sheet, break it in two and have two, 2’ wide sheets (middle score), or you can break it into three 16” wide pieces by snapping at the left and right score.
  • Click here to shop Loctite foamboard adhesive
  • Click here to learn more about Eco Options and Energy Efficiency

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Foam Board Insulation

24 in. x 1 in. x 48 in. R5 Radiant Acoustic Insulation Kit - STC 19 (5-Piece)0.625 in. x 48 in. x 24 in. 72 sq. ft. R-3 Graphite Radiant Barrier Wall Insulation Kit (9-Sheets/Kit)19 in. x 150 ft. Sticky Mesh Heavy Duty
current product
FOAMULAR 150 2 in. x 4 ft. x 8 ft. R-10 Scored Squared Edge Rigid Foam Board Insulation Sheathing
BrandSilveRboardSilveRboardSTYRO IndustriesOwens Corning
Name24 in. x 1 in. x 48 in. R5 Radiant Acoustic Insulation Kit - STC 19 (5-Piece)0.625 in. x 48 in. x 24 in. 72 sq. ft. R-3 Graphite Radiant Barrier Wall Insulation Kit (9-Sheets/Kit)19 in. x 150 ft. Sticky Mesh Heavy DutyFOAMULAR 150 2 in. x 4 ft. x 8 ft. R-10 Scored Squared Edge Rigid Foam Board Insulation Sheathing
Price
Ratings
(236)
(14)
(49)
(175)
Product Thickness (in.)1 in.625 in0.0752 in
Insulation Location2x4 Wall,2x6 Wall,2x8 Wall,Attic,Basement,Ceiling Insulation,Exterior Sheathing,Garage,Metal Building,Re-Siding2x4 Wall,2x6 Wall,2x8 Wall,Attic,Basement,Ceiling Insulation,Crawlspace,Exterior Sheathing,Garage,Metal Building,Re-SidingBasement,Ceiling Insulation,Exterior Sheathing,Exterior Wall,Exterior Wall Foundation,Interior Ceiling,Interior Wall,Wood SidingExterior Sheathing
Insulation R-ValueR5R3.0 R10
Sheathing TypeEPSEPSEPSXPS
Insulation FeaturesFormaldehyde Free,Vapor RetardantFormaldehyde Free,Moisture Retardant,Mold Resistant,Soundproofing Insulation,Vapor RetardantMold ResistantFormaldehyde Free
Product Length (ft.)2 ft18 ft1508 ft
Compatible Install SurfaceCement,Concrete,Existing Drywall,Existing Insulation,PlywoodCement,Concrete,Existing Drywall,Existing Insulation,PlywoodCement,Concrete,Existing Drywall,Existing Insulation,Fiberglass,Plywood,WoodPlywood,Wood
Faced or UnfacedFacedFacedUnfacedUnfaced
Product Width (in.)48 in48 in1948 in
Interior/ExteriorInterior/ExteriorInterior/ExteriorInterior/ExteriorExterior
View ProductView ProductView ProductView Product

Specifications

Dimensions

Coverage Area (sq. ft.)
32
Product Length (ft.)
8 ft
Product Thickness (in.)
2 in
Product Width (in.)
48 in

Details

Compatible Install Surface
Plywood,Wood
Faced or Unfaced
Unfaced
Insulation Features
Formaldehyde Free
Insulation Location
Exterior Sheathing
Insulation R-Value
R10
Insulation Type
Foam Board Insulation
Interior/Exterior
Exterior
Number of Pieces
1
Pack Size
1
Product Weight (lb.)
7.87 lb
Sheathing Size
8 ft. x 2 in. x 48 in.
Sheathing Type
XPS

Warranty / Certifications

Warranty Information
Limited Lifetime

Questions & Answers

202Questions25Answers

Can I bend this product to fit a curve with reducing the integrity? Or would it need to be cut?

Asked by Cid April 29, 2021
4
Answers

The 2 inch thick boards are fairly rigid and are not very bendable. If the curve is very slight, you might be able to get away with it otherwise you'll probably need to cut it.

I'm looking at foam products that can be used to create a faux ceiling beam. The beam will cover...

Asked by Tracy April 28, 2021
2
Answers

Hello Tracy, Owens Corning Foamular products are combustible an cannot be left exposed. The Foamular would need to be covered by a 15 minute thermal barrier such as 1/2" drywall. Thank you for your inquiry!

Can this product be used to cover foundation and be in ground contact?

Asked by AJ April 25, 2021
2
Answers

It can be used below grade but the foundation walls themselves must provide the waterproofing.

can I use 2 inch foam board to insulate the underneath of afloor in a damp crawl space?

Asked by Wildfire April 9, 2021
2
Answers

Hello Wildfire, Foamular will not solve a moisture issue in a crawlspace. The crawlspace should have a 10 mil poly covering the entire floor with any seams overlapped and sealed as well as sealing the poly to the perimeter walls. If this is already in place or there is still a moisture issue call in a contractor/expert to deal with the moisture issue. If a floor is to be added over the poly with Foamular below it then the Foamular must be completely covered by a thermal barrier. ¾” osb is typically accepted as a thermal barrier. Thank you for your inquiry!

How do u install on plastic siding on mobile home

Asked by dot March 27, 2021
2
Answers

Cut to fit and glue with construction adhesive.

Which 2” insulation board is the most rigid?

Asked by James March 19, 2021
1
Answer

Hello James, The most rigid Foamular board that Owens Corning sells at Home Depot is the 2” F-250. Please note that all Foamular boards can flex with wind pressure, so we suggest framing the window opening with the same framing used for the wall and attaching the Foamular to that framing. Thank you for your inquiry!

Can it be applied to sides of aluminum barn walk

Asked by David March 16, 2021
2
Answers

I would think if you use a good adhesive (liquid nail or something like that) it would stick to the aluminum, but that is a guess only. I'd do a quick GOOGLE search and see if anyone else has tried that. Thank you!

Can this be painted, thinking of using for a dart board surround.

Asked by Steve March 9, 2021
5
Answers

Yes it can be painted, would use a water based paint

I am thinking of making a hot tub cover with this product. I know it is water resistant, but woul...

Asked by Hottubcover January 1, 2021
3
Answers

Hello Hotubcover, Owens Corning does not make recommendations on using the Foamular product as a hot tub cover. It does have a service temperature of 165° F. However, it cannot be exposed to UV for extended amount of time. Thank you for your inquiry!

Can this foam board be used in a flue chase above a gas burning fireplace? Can it touch the flue or must it be 2" away?

Asked by Bob September 20, 2020
2
Answers

Hello Bob, Owens Corning Foamular has a service temperature of 165° F and should not be in contact with the flue. Thank you for your inquiry!

FOAMULAR 150 2 in. x 4 ft. x 8 ft. R-10 Scored Squared Edge Rigid Foam Board Insulation Sheathing - page 2

Customer Reviews

  • 4.8
    out of 175 reviews
  • 100% recommend this product
Filter by:
Showing 1-10 of 175 reviews
I have used this insulation on several projects
This 2 inch foam insulation has been used on several projects in the last 10 years. Last year I built a 6 ft by 9 ft temporary RV to use on a job, now I use it as a storage shed. This year I am building a 5 ft by 12 ft trailer and I'm using it again because it worded so well. Sadly the price has increased by about 33% from $32 to around $39 but still worth it to me.
by TexasBob
1 person found this helpful
I've used this product for several applications. In this case I have a room under our front porc...
I've used this product for several applications. In this case I have a room under our front porch, which is mostly underground; I want to turn it into a wine cellar. Doing this will help control the temperature enough to store wire, I hope. It won't be anything fancy, but I figured using this rigid insulation will not take up as much space & I don't need to build any kind of stud wall to install it. I am gluing it to the walls with a construction adhesive specifically for foam insulation. It does need to be clamped in place in order to the glue to hold the foam as I intended. To cut the product I simply score it with a utility knife on both sides & snap it like dry wall. I routed out a channel for wiring, which worked well.
by MarkFred
1 person found this helpful
Very easy to install ... durable (walked on it after and my 270 husband did not dent it).
Very easy to install ... durable (walked on it after and my 270 husband did not dent it).
by RandGFarms
1 person found this helpful
Nice to work with. Seems to cut cleaner with a utility knife than the Dow Styrofoam. It also seem...
Nice to work with. Seems to cut cleaner with a utility knife than the Dow Styrofoam. It also seems to a little denser and less prone to damage.
by Jeff
1 person found this helpful
Excellent product that's easy to work with.
Excellent product that's easy to work with.
by HomeDepotCustomer
1 person found this helpful
We installed Foamular 150 2 inches 4x8 ft into our house's attic. It seems that the space covered...
We installed Foamular 150 2 inches 4x8 ft into our house's attic. It seems that the space covered be immediately warmer and look better. Attached is the photo of our action using the product. ZH13
by ZH13
After researching the net for insulation not only for a crawl space and a basement I felt this wo...
After researching the net for insulation not only for a crawl space and a basement I felt this would be the best product for the application. This was easy cutting this Formular 150 R-10 2" insulation in any dimension via a Olfa knife, circular saw and or a table saw. I completed most of my cuts prior to installation and installation was much easier and time efficient. I have already completed the installation 11/23/18 on the crawl space (encapsulated the crawl) and have already observed a savings in heating costs by 18% and the floors are much warmer by 8 degrees. I no longer smell the dank crawl space and the interior environment of the house has improved 100%. I am not encapsulating the basement; however, I will use this on all of the walls and fascia boards to effectively do the same as the crawl. I have calculated the return on investment at approximately 18 to 24 months. I would highly recommend this product and it definitely met my expectations.
by RonL
2 people found this helpful
Easy to work with.
Easy to work with.
by Rv
I am re-insulating my attic by adding R-30 un-faced rolls perpendicular to the ceiling joists. I ...
I am re-insulating my attic by adding R-30 un-faced rolls perpendicular to the ceiling joists. I used the 2" foam to build an attic stairway insulated cover. I built a frame with hinges to attach it too - if I ever build another one, I may just glue the foam together w/o the frame to see if it will work by itself.
by
3 people found this helpful
I'm so happy to see thicker versions of this product at my Home Depot! I use this stuff to air s...
I'm so happy to see thicker versions of this product at my Home Depot! I use this stuff to air seal walls and ceiling spots. Cut to size and then seal in w/ my Great Stuff PRO gun. On brick walls I fill the void between brick and studs with ROXUL safe n sound and then seal the stud void w/ foam. This gives me a fire block, fills the void eliminating a home for bugs/critters, makes wall air/water tight. Also if you expose studs go ahead and treat them w/ borate to kill any termites that try to nibble on your framing..just paint the bottom 2-3ft w/ it. This 2 inch variant of the Foamular translates to less cutting for me. It takes 3 inches to fill a 2x4 stud wall, I wish they sold the 3" thickness then I'd only have to cut one time. This does does dull utility knives quickly just a heads up buy an extra pack of blades. Attached picture shows this product along with the other foam that has a radiant barrier. I use 2 layers of foamular along w/ the radiant barrier version in most areas.
by KungfuMonkey
6 people found this helpful
