Simpson Strong-Tie

2 in. x 1-1/2 in. x 1-3/8 in. ZMAX Galvanized Angle

Name: 2 in. x 1-1/2 in. x 1-3/8 in. ZMAX Galvanized Angle
Brand: Simpson Strong-Tie
SKU: 296044
Price: 0.78 USD
Availability: InStock
Rating: 4.6316 (209 reviews)

(210)Questions & Answers (18)

78¢

Buy 30 or more 70¢

Industry leader in structural hardware engineering since 1956
Products designed and tested for strength and easy installation
Diverse product line for DIY and residential
View More Details

Store

0 in stock

Product Details

Not only do angles make joints stronger, they also provide more consistent, straight corners. Simpson Strong-Tie offers a wide variety of angles in various sizes and thicknesses to handle light-duty jobs or projects where a structural connection is needed. Some can be bent (skewed) to match the project. For outdoor projects or those where moisture is present, use our ZMAX zinc-coated connectors, which provide extra resistance against corrosion (look for a "Z" at the end of the model number).

Versatile connector for various 90-degree connections and home repair projects
Stronger than angled nailing or screw fastening alone
Help ensure joints are consistently straight and strong
Made from 18-gauge steel
ZMAX galvanization offers extra corrosion resistance for exterior and treated-wood applications
ZMAX galvanization offers extra corrosion resistance for exterior and treated-wood applications
Install with 10d x 1-1/2 in. nails or #9 x 1-1/2 in. Strong-Drive SD screws
Shop all Simpson Strong-Tie here.
Return Policy

Additional Resources

From the Manufacturer

Questions & Answers

Q:Will like to disassemble my project. So instead of using #9 x 1-1/2 in. Strong-Drive SD screws. Is it possible to use flanged tapping inserts and hex screws to attach the L bracket?

by|Mar 8, 2022

1 Answer

Answer This Question

A: Hello Mango, this is McKenzie with Simpson Strong-tie. To achieve the published load resistance in our catalog, the only approved and tested fasteners are either 1.5" #9 SD screws or N10 (0.148" x 1.5") nails. Good luck with your project!

by|Mar 8, 2022

Q:Will these work to attach both ends of a 1x4 to the inside of 4x4 fence post?

by|Jun 2, 2020

4 Answers

Answer This Question

A: Advise using two on each end attach with screws.

by|Oct 30, 2022

A: If I understand the question correctly the answer is yes.

by|Jun 5, 2020

A: Yes, in fact I used it for this purpose.

by|Jun 9, 2020

A: I have used Simpson products to fix wooden fences many times. You use it in combination with either the special screws, or with short deck screws. Yes, this will help your fence.

by|Nov 28, 2022

1 found this answer helpful

Q:Can I use #10 1-1/4 inch screws with these

by|May 30, 2020

4 Answers

Answer This Question

A: Holes are about 0.168" and a #10 screw is 0.190" at shank and 0.130" at root of threads.

by|May 23, 2021

1 found this answer helpful

A: Yes you can i used these with 1 1/4 in screws to hold 2x4s in place . I also used 2 in screws also in tge 2x4 and both plate boards

by|Jun 3, 2020

A: As our helpful friends have said in possibly too technical a fashion, a #10 screw is too thick for the existing hole size, #9 or #8 screws are much better choices.

by|Jul 29, 2022

3 found this answer helpful

A: The A21Z is to be installed with either 0.148" diameter x 1 1/2" long nails or SD9112 Strong-Drive SD Structural Connector screws. Thank you!

by|Dec 22, 2022

2 found this answer helpful

Q:Can I use this on concrete to hold a 4x4 post?

by|Apr 16, 2020

3 Answers

Answer This Question

A: Yes but not strong enough. HD sells 90s that are short on one side and heavy

by|Apr 30, 2020

A: The A21Z is only rated for wood-to-wood applications. It would be up to the Designer to specify the appropriate connector, but you can find several options of post bases on our website. Thank you!

by|Apr 17, 2020

A: Can do that, but really needs stronger fasteners than this can provide.

by|Jun 11, 2020

Customer Reviews

4.7 out of 5

(210)

4.7
out of 210 reviews
98%recommend this product

161

Filter by:

Showing 1-10 of 210 reviews

Apr 30, 2020

I used the bracket for holding the picket fence tightly in this section on top and on the bottom ...

I used the bracket for holding the picket fence tightly in this section on top and on the bottom the lower prices silver brackets. I liked using these instead of toenailing.

Verified Purchase

Recommended

Feb 18, 2020

We've used 100+ of these little guys for decks, raised garden beds and pergolas. Excellent!!!

Verified Purchase

Recommended

Oct 15, 2019

I've used Simpson for years, and they never let me down

Verified Purchase

Recommended

Aug 20, 2018

I used these as a means to secure stair stringers to my deck. They helped add stability. I secure...

I used these as a means to secure stair stringers to my deck. They helped add stability. I secured them with galvanized 1.5" screws.

Recommended

4 found this review helpful

Mar 29, 2023

Verified Purchase

Mar 23, 2023

I'm only disappointed that the same ties that HD has...

I'm only disappointed that the same ties that HD has for sale .88 in store and have to order online to get .44. Why not the same price online and in store?
