#1 Home Improvement Retailer

Internet # 304811992

Model # NEM5466UC

Store SKU # 1003948396

Store SO SKU # 1003282750

500 Series 24 in. Radiant Electric Cooktop in Black with 4 Burner Elements including 2,200-Watt Burner Boil Time

$949.00
Apply Now
$undefined.00 /mo† suggested payments with months† financingApply Now
  • Precise Temperature Control for Better Cooking Results
  • Ceramic-Glass Surface Makes Cooking and Cleaning Especially Easy
  • Ideal for Kitchens With a Small Footprint
  • View More Details

Product Details

About This Product

Bosch cooktops are designed to deliver perfect results with minimal effort. Whether you chose induction, gas, or electric, every Bosch cooktop combines simplicity with intuitive usability. So recipes are followed more efficiently, meals are made quickly, and cleanup happens easily. Because at the end of a long day, Bosch believes cooking should bring joy, not frustration. The 24 in. electric cooktop, sleek in design, features precise temperature control and is ideal for small spaces.

Highlights

  • 4 element electric cooktop includes a 2,200W left rear element for faster boil times
  • Push-to-turn control knobs allow for simple heat level adjustment
  • Ceramic-glass surface makes cooking and cleaning easy
  • Residual heat indicator for each zone
  • Black-glass seamless design - simple and sleek, the timeless electric cooktop delivers precision performance and is easy to clean
  • Precise temperature control for better cooking results
  • Variable 9-stage power settings for each zone
  • Cooktop design coordinates with Bosch ovens and ventilation
  • Ideal for smaller spaces
  • Check with your local The Home Depot store for installation options
  • Click here to view a product guide to help you select your compatible Bosch Range Hood
  • Click here to shop for more Bosch Appliances
  • California residents
     see Prop 65 WARNINGS

Product Information

Internet # 304811992

Model # NEM5466UC

Store SKU # 1003948396

Store SO SKU #1003282750

Specifications

Dimensions: H 4.46, W 23.5 in, D 20.5 in

Specifications

product
Features
RadiantIndicator Light- Hot Surface Indicator LightIndicator Light- Heating Element On

Dimensions

Cooktop Size

24 in.

Cut-Out Front to Back Depth (in.)

19.25

Cut-Out Height (in.)

4.33

Cut-Out Left to Right Width (in.)

22

Element #1 Size (in.)

7

Element #2 Size (in.)

6

Element #3 Size (in.)

6

Element #4 Size (in.)

8

Product Depth (in.)

20.5 in

Product Height (in.)

4.46

Product Width (in.)

23.5 in

Details

Amperage (A)

30 A

Appliance Category

Cooktop

Appliance Series

Bosch 500 Series

Appliance Type

Electric Cooktop

Color/Finish

Black

Color/Finish Family

Black

Commercial/Residential

Residential

Control Location

Right

Cooktop Control Type

Standard Dial Control

Cooktop Features

Indicator Light- Heating Element On, Indicator Light- Hot Surface Indicator Light, Radiant, Unit can be installed over a Wall Oven

Cooktop Surface Type

Smooth Top

Element #1 Wattage

1800

Element #2 Wattage

1850

Element #3 Wattage

1200

Element #4 Wattage

2200

Element No.1 Type

Radiant

Element No.2 Type

Radiant

Element No.3 Type

Radiant

Element No.4 Type

Radiant

Fuel Type

Electric

Number of Elements

4 element

Product Weight (lb.)

20 lb

Returnable

Non-Returnable

Voltage (V)

240

Warranty / Certifications

Certifications and Listings

CSA Listed, UL Listed

Manufacturer Warranty

1 Year Limited

Questions & Answers

11Questions
caret
Q:How many AMPs are required for this cooktop
by|May 16, 2024
1 Answer
Answer This Question

A:  Hi Sandy, thanks for your question. 30 Amps are required for this cooktop. You can refer to the spec sheet here for the complete technical information: https://bit.ly/4bJUdY3

by|May 30, 2024
    caret
    Q:Does this cooktop work with 208 volts
    by|Apr 14, 2024
    1 Answer
    Answer This Question

    A:  Hi gillian, thanks for your question. Yes, model NEM5466UC will work with 208 volts.

    by|Apr 16, 2024
      caret
      Q:show dimentions.
      by|Nov 5, 2023
      1 Answer
      Answer This Question

      A:  Hi Glenn, thanks for your interest in model #NEM5466UC. The overall product dimensions and required cutout sizes are provided in the Product Specification Sheet here: https://media3.bosch-home.com/Documents/MCDOC01759269_NEM5466UC.pdf.

      by|Nov 8, 2023
        caret
        Q:Is this an induction cooktop?
        by|Apr 8, 2023
        1 Answer
        Answer This Question

        A:  Hi JENNIFER, thanks for your question and interest in model NEM5066UC. No, this is not an induction cooktop, it is a 500 series electric cooktop.

        by|Apr 10, 2023
          Showing 1-4 of 11

          Customer Reviews

          4.6 out of 5

          • 4.6 out of 17 reviews
          • 80% recommend this product
          Filter by:
          Showing 1-10 of 17 reviews
          Electric Cook Top
          [This review was collected as part of a promotion.] I have a small kitchen, so I chose the 24" cook top, and even with using all 4 burners at once, I had no problem with space issues. It is quite good looking and many think I got the induction cook top. Yes, the burners on this get hot and burned on food can happen, but a little baking soda and white vinegar make it easy to clean. Bosch also has a nice glass cook top cleaner. I'm purring! :)
          by
            • Recommended
            Cook top
            [This review was collected as part of a promotion.] Small and sleek . Love it. Replaced a 40 year old awful cooktop
            by
              • Recommended
              Great Cooktop
              Works well, fast and easy to clean ( aside form the part where the knobs are - that takes some extra patience ) . Looks very nice in modern kitchen . It would be better if knobs did not exist and that whole peace was completely flat .
              by
                Works well but is a little difficult to use and...
                Works well but is a little difficult to use and very difficult to keep clean. Heat level numbers around dials faint and hard to read. Residue forms over burners after every use that requires glass cooktop cleaner to clean. Knobs do not come off for easy cleaning.
                by
                • Verified Purchase
                2 found this review helpful
                Rating provided by a verified purchaser...
                Rating provided by a verified purchaser
                by
                • Verified Purchase
                Electric cooktop
                My cooktop has some places that I can not remove.
                by
                  Electric cooktop
                  [This review was collected as part of a promotion.] My cooktop has a place I cannot remove
                  by
                    Best Quality
                    [This review was collected as part of a promotion.] This cooktop is efficient,of high quality and stylish. Simple design with efficient features It lives up to the Bosch name. I Highly recommend.
                    by
                      Looks good and does the job....
                      Looks good and does the job.
                      by
                      • Verified Purchase
                      • Verified Purchase
                      • Recommended
                      Showing 1-10 of 17 reviews
