#1 Home Improvement Retailer

Internet # 314138052

Model # JGB735DPBB

Store SKU # 1005743530

Store SO SKU # 1005743530

30 in. 5.0 cu. ft. Gas Range with Self-Cleaning Convection Oven and Air Fry in Black

$1028.00
$1149.00
Save $121.00 (11%)
Apply Now
$undefined.00 /mo† suggested payments with months† financingApply Now
  • Air fry healthier, crispier options with no preheat needed
  • Continuous cooktop provides a large cooking space
  • An extra-large griddle allows you to cook a lot at once
  • View More Details

Product Details

Lifestyle image of woman and young girl cooking near a free-standing range with GE Appliances logo appearing in the bottom right corner

Appliances That Bring Good Things, To Life

Whether you're doing dishes, laundry or cooking, GE Appliances products are designed for real life.

Free-standing range installed in the kitchen

Built By The Appliance Brand You Trust

Ranges from GE Appliances bring durability and long-lasting performance to your home, so you never miss a beat.

In-oven image of chicken wings cooking with airflow arrow graphics

No-Preheat Air Fry

Air fry crispy foods in the oven without using oil and skip the preheat for a shorter cook time.

6 grilled cheese sandwiches cooking on a center griddle

Integrated Griddle

This integrated non-stick griddle leads the industry in size and quality, so you can cook a lot of food at once.

Power boil burner on with saucepan over the flame

Power Boil Burner

This 18,000-BTU power boil element produces intense heat to boil water fast.

Biscuits baking in a convection oven

Convection

This convection oven cooks and browns more evenly by using a rear fan to circulate hot air.

Dirty oven becomes clean with self-clean steam setting

Self-Clean with Steam Clean

This self-cleaning oven has optional steam cleaning to remove light soils with less heat and odor.

An icon of the appliance with arrows measuring its capacity

Capacity

Cook multiple dishes at the same time with 5.0 cubic feet of capacity.

An icon of one of the cast iron grates. It sparkles with cleanliness after being washed in the dish washer.

Dishwasher-Safe Grates

Grates can be cleaned in the dishwasher or inside the self-clean oven.

An icon of a smooth-glide roller rack. Arrows show it sliding out smoothly.

Optional Roller Rack

This optional roller rack makes removing heavy or odd-size cookware easy and safe.

An icon of an electrical cord and plug with a disconnect in the center, signifying certain features being deactivated while in Shabbos mode.

Sabbath Mode

Observe religious holidays by using a setting that disables all electrical activity.

An icon of a ribbon with a checkmark in the center of it.

Warranty

Choose GE Appliances without worry or hesitation, thanks to an extensive warranty.

An icon of the appliance viewed from a corner looking down. Lines designate and measure the height, width, and depth of the appliance.

Dimensions

W 30 in. x H 47.25 in. x D 28.75 in.

About This Product

At GE Appliances, we bring good things to life, by designing and building the world's best appliances. Our goal is to help people improve their lives at home by providing quality appliances that were made for real life. Whether it's enjoying the tradition of making meals from scratch or tackling a mountain of muddy jeans and soccer jerseys, GE Appliances are crafted to support any and every task in the home.

Highlights

  • No Preheat Air Fry - With this air fryer right in the oven, you can cook healthier, crispier versions of your favorite foods. There's no preheat required and it shortens the cook time because every minute counts
  • Edge-to-Edge Cooktop - Continuous, edge-to-edge cooktop give you a large cooking space and can handle any cookware
  • Integrated Griddle - This integrated non-stick griddle leads the industry in size and quality, so you can cook a lot of food at once
  • Power Boil Burner - This 18,000-BTU power boil element produces intense heat to boil water fast
  • Convection - This gas convection oven cooks and browns more evenly, using a rear fan to circulate hot air.
  • Purchase a heavy duty dishwasher safe grate accessory JXGRATE1 (sold seperately)
  • Self-Clean with steam clean - this self-cleaning oven uses optional steam cleaning for light soils to clean the oven cavity with less heat and odor
  • Center oval burner - this center oval burner gives you a fifth burner and the perfect place to use griddles or odd-size cookware
  • Heavy Duty, Dishwasher-Safe Grates - These cooktop grates can be cleaned one of two ways - either in the dishwasher, or on the bottom of a self-clean oven
  • Large capacity oven - cook an entire meal at once with a 5.0 cu. ft. oven which provides enough room for multiple dishes
  • Optional Roller Rack - An optional roller rack which makes removing heavy or odd-size cookware easy and safe
  • Removable Storage Drawer - A full-width drawer provides space for kitchen accessory and cookware storage for added convenience in the kitchen
  • Limited 1-year entire appliance warranty
  • Installation is not available in all locations. See store for details.
  • Installation is not available in all locations; see store for details
  • Click here to shop more GE appliances
  • California residents
     see Prop 65 WARNINGS

Product Information

Internet # 314138052

Model # JGB735DPBB

Store SKU # 1005743530

Store SO SKU #1005743530

Specifications

Dimensions: H 47.25 in, W 30 in, D 28.75 in

Specifications

Dimensions

Depth With Door(s) Open 90 Degrees (in.)

46.25 in

Oven Interior Depth (in)

19

Oven Interior Height (in)

19

Oven Interior Width (in)

24

Product Depth (in.)

28.75 in

Product Height (in.)

47.25 in

Product Width (in.)

30 in

Range Size (Width)

30 in.

Details

Appliance Category

Range

Appliance Series

Not Applicable

Appliance Type

Gas Range

Burner Grate Material

Cast Iron

Burner No.1 BTU

12000

Burner No.2 BTU

5000

Burner No.3 BTU

10000

Burner No.4 BTU

18000

Burner No.5 BTU

9500

Capacity of Oven (cu. ft.)

5 cu ft

Capacity of Oven (cu. ft.)

5 cu ft.

Cleaning Type

Self Cleaning

Color of Cooktop

Black

Color/Finish

Black

Color/Finish Family

Black

Commercial/Residential

Residential

Control Type

Electronic

Controls Location

Back Control

Cooktop Features

Continuous Grates, Power Element, Sealed Burners, Simmer Element, With Griddle

Cooktop Surface Type

Griddle

Drawer Type

Lower Storage Drawer

Fuel Type

Gas

Hardware Color/Finish

Black

Hardware Color/Finish Family

Black

Ignition Type

Electrical

Included

No Additional Items Included

Number of Burners

5 burner

Number of Oven Racks

2

Number of Rack Positions

5

Oven Cleaning Options

Self-Cleaning, Steam Clean

Oven Cooking Process

Air Fry, Convection

Oven Features

Broiler in Oven

Product Weight (lb.)

190 lb

Range Installation Type

Freestanding

Returnable

Non-Returnable

Warranty / Certifications

Certifications and Listings

Star-K, UL Listed

Manufacturer Warranty

Limited 1-year entire appliance

Questions & Answers

862Questions
caret
Q:Is this self venting
by|May 19, 2024
1 Answer
Answer This Question

A:  This range is not a downdraft system range. If you need venting for your kitchen, we have some great range hoods and over the range microwaves that would be great in your home!

by|May 20, 2024
    caret
    Q:Does the depth measurement include the door handle?
    by|May 9, 2024
    1 Answer
    Answer This Question

    A:  The depth without the handle is 26-1/4” and the depth with the handle is 28-3/4”. For a helpful illustration and more dimensions, check out the Specifications: https://images.thdstatic.com/catalog/pdfImages/ed/edda5c51-6ba3-4990-91c0-4f3ac746c298.pdf

    by|May 9, 2024
      caret
      Q:Who do we contact if any feature on the stove stops working?
      by|May 5, 2024
      1 Answer
      Answer This Question

      A:  We do not anticipate thta you'll have any issues out of your range! However, should you need it, you do have a one-year warranty with us that you can take advantage of by calling 833-426-3393. Thank you for choosing GE Appliances!

      by|May 6, 2024
        caret
        Q:Does it come with a conversion kit to hook up to propane?
        by|May 5, 2024
        1 Answer
        Answer This Question

        A:  This range certainly does come with the LP conversion kit! We do recommend having this conversion done by a qualified gas installer. Thank you for checking in with us and for choosing GE Appliances.

        by|May 23, 2024
          1 found this answer helpful
          Showing 1-4 of 862

          Customer Reviews

          4.7 out of 5

          • 4.7 out of 7,445 reviews
          • 95% recommend this product
          Filter by:
          Showing 1-10 of 7,445 reviews
          Gas range stove good, in oven paint shaving off
          For a normal gas oven stove after 5 months use, good. Can't quite figure out the air fry system. no tips or videos on how to properly use this feature in manual. Best I can find on YT is people using stand alone fryers. Need more content. Also for the center burner on top, terrible quality included pancake griddle. I got lucky to find a sale on the cast iron griddle and cast iron burner grills and got them while still available. BAD PAINT IN OVEN. chipping off with normal oven use (in and out of the racks)
          by
          Response from GE_AppliancesMay 17, 2024
          We'd like to assist you with the air fry mode. Please refer to this link here for some helpful information: https://products.geappliances.com/appliance/gea-support-search-content?contentId=000061389 We want to ensure you get the assistance you need, and an agent will be reaching out to you by email.
            Awesome stove
            Love the new stove and all the features. The stainless steel looks amazing. And super excited about the air fry feature.
            by
              • Recommended
              Awesome Range!
              Love this Range!! Converted to propane and it’s elite!!
              by
                • Recommended
                Great gas range!
                The range is beautiful in our kitchen and works wonderfully!
                by
                  • Recommended
                  Loaded with features
                  Looks like a great unit. No damage at all and easy to unpack/ set up
                  by
                    • Recommended
                    Great features and good looking
                    So far I am very happy with this new stove. The burners adjust well from high to very low. I love having the griddle as part of the stove but it is difficult to keep it looking new.
                    by
                      • Recommended
                      Great features
                      Love the look and the air fryer. Very even cooking
                      by
                        • Recommended
                        Great features
                        I love the sleek appearance. The stove top is large and the grates are heavy duty. Cleaning the stove top and oven is a breeze. The convection oven and air fryer are wonderful features.
                        by
                          • Recommended
                          Oven
                          works well. heats fast, looks good too. Clock becomes hidden when baking since it uses same spot as oven temperature display.
                          by
                          Response from GE_AppliancesMay 2, 2024
                          Thank you for your review and feedback. We’re so happy to hear that you have been enjoying your new range and how quickly it is able to heat your cookware.
                            We LOVE this stove! The oven is huge but the whole stove takes up very little room. It does everything! Best choice we could have made!
                            by
                            Response from GE AnswersApr 30, 2024
                            Thank you for choosing us for your home! We are happy to hear you are loving your new GE Appliance gas range and it fits perfectly in your space. This unit is packed with some really great features that we are sure you will be impressed with for many years. GE_Appliances
                            • Verified Purchase
                            Showing 1-10 of 7,445 reviews

                            What We Offer

                            Delivery

                            Services

                            We offer move or haul away services, and installation on most appliances when you purchase required parts.
                            Installation Requirements

                            The Home Depot

                            Protection Plan

                            Get 24/7 support and our 3-day Service Guarantee
                            Plan Coverage and Details

                            48-Hour

                            Return Policy

                            You can return your appliance for damages and defects within 48 hours.
                            Return Policy

                            Price Match

                            Guarantee

                            We will match prices including shipping of any other online competitor.
                            Learn More

                            Delivery and Installation

                            thumbnail
                            Home Depot Gas Range Delivery & Installation
                            This video will walk you through the simple steps you must take in order to ensure a successful delivery and installation of your new Gas Range from The Home Depot.

                            Please ensure the following prior to delivery:

                            • New gas flex connection kit
                            • Natural gas line (no liquid propane hookups)
                            • 110V-grounded, 3-prong electrical outlet
                            • Gas shutoff directly behind the appliance
                            • Verify your existing electrical & water connections
                            • Empty & unplug your old appliance
