- Manual-ranging multimeter tests batteries, diodes and continuity
- Volt Tester measures up to 600 VAC/VDC voltage and 10A DC current
- Electrical Tester for multi-purpose residential and industial use
- View More Details
Free & Easy Returns In Store
Return this item within 90 days of purchase.
Ask about this product
Get an answer now with AI
Magic Apron Assistant is an AI virtual assistant. By proceeding, you consent to the recording and use of your information by The Home Depot (and authorized third parties). More information
Product Details
About This Product
Klein Tools MM300 Multimeter is a manual ranging multimeter that measures AC/DC voltage, DC current, and resistance. It can also test batteries, diodes, and continuity. Klein Tools' Test and Measurement product line was exclusively designed from the ground up by electricians for electricians. Years of field research, combined with extensive input from electricians across America, inspired the development of meters and electrical testers loaded with innovative, time-saving features.
Highlights
- Digital multimeter measures up to 600V AC/DC voltage, 10A DC current and 2MOhms resistance
- Voltage tester for batteries, diodes and continuity
- Built to withstand a 3.3 ft. (1m) drop and withstand daily wear and tear on the job site
- For use in basic and controlled electromagnetic environments such as residential, business and light-industrial locations
- CAT III 600V safety rating
- Low battery indicator and easily accessible battery compartment
- Includes test leads, batteries and user manual
- Click Here to Learn More on How to Use Electrical Testers and Meters
- Click here for more Klein Tool products
- Shop all Klein Tools electrical testers here
- Click here for more information on Electronic Recycling Programs
- Return Policy
- California residentssee Prop 65 WARNINGS
Product Information
Specifications
Dimensions
Product Depth (in.) | 1.78 in |
|---|---|
Product Width (in.) | 3.07 in |
Details
Accuracy Measurement | Non-RMS |
|---|---|
Category Rating | III |
Features | Audible Alert, Data Logging, Interchangeable Leads |
Functions Measured | Amperage, Continuity, Resistance, Voltage |
Included | Batteries |
Maximum AC Current (A) | 0 |
Maximum AC Voltage | 600 |
Maximum DC Voltage | 600 |
Maximum Frequency (MHz) | 0 |
Maximum Resistance (ohms) | 2M |
Number of Functions | 16 |
Power Source | Battery Operated |
Range | Manual Ranging |
Returnable | 90-Day |
Warranty / Certifications
Certifications and Listings | CE Certified |
|---|---|
Manufacturer Warranty | Please refer to the attached warranty document in the Product Overview section above under Info & Guides. |
Questions & Answers
What dose OL stand for?
On the Klein Tools Cat. No. MM300, Digital Multimeter, Manual-Ranging, 600V, “OL” indicates an open circuit when testing continuity. During diode testing, it indicates reverse bias or an open device.
Operation of a Klein multimeter model mm100
The Klein Tools Cat. No. MM300, Digital Multimeter, Manual-Ranging, 600V includes an instruction manual with detailed operating instructions for measuring voltage, current, resistance, continuity, diodes, and batteries. Please refer to the instruction manual that was included with the meter for complete operating instructions. If you no longer have the manual or need additional assistance, please contact Klein Tools Customer Service at customerservice@kleintools.com and we will be happy to help.
What can be done if ohm test function does not work ?
Please contact Klein Tools Customer Service 1-800-553-4676 for assistance with your meter.
Does it come with calibration certification
For information on calibration certification please contact Klein Tools Customer Service 1-800-553-4676
For information on calibration certificates please contact Klein Tools Customer Service 1-800-553-4676
Does that voltage meter come with the batteries
Yes, batteries are included.
how long are the leads for MM325
39 in.
Will it measure millivolts on a gas furnace thermopile?
The Klein Tools MM300 Multimeter will measure DC millivolts.
Since the meter is not auto-ranging, does the MM300 have over range or over voltage protection?
The Klein Tools MM300 Multimeter has 2 replaceable fuses: 200mA/600V fast-blow fuse (Klein Cat. No. 69031) 10A/600V fast-blow fuse (Klein Cat. No. 69032)
Viewing 1-8 of 33
