4/10 HP Submersible Pre-Assembled Simplex Sewage System with Side Discharge and LE41 Pump

$699.00
/pallet
Apply Now
Pay $649.00 after $50 OFF your total qualifying purchase upon opening a new card. info
Apply for a Home Depot Consumer Card
Store
0 in stock
icon
Free & Easy Returns In Store or Online
Return this item within 90 days of purchase. Read Return Policy
Product Details

About This Product

The Pro380-Series is a large capacity shallow system design featuring a 24 in. x 24 in. basin - perfect for bedrock and difficult soil conditions. The Pro380-Series offers a large 41 Gal. capacity and longer pump cycles for extended pump life. The Pro380-Series sewage package arrives from the factory pre-assembled saving valuable labor time at the job site. Now available alarm-ready with pre-mounted alarm floats. Give the Pro380 a try and see why more contractors demanding Liberty are. The Pro-Series is backed by Liberty's standard three-year warranty.

Highlights

  • 2 in. side discharge
  • Quick tree float system allows easy removal of floats without pulling the pump
  • Shallow 24 in. basin for easier burial in difficult soil conditions
  • Large 41 Gal. capacity
  • Anti-flotation collar
  • Return Policy
  • California residents
     see Prop 65 WARNINGS

Product Information

Internet # 321398314

Model # P382LE41SD-2

Store SKU # 1008112378

Specifications

Dimensions: H 24 in, W 24.38 in, D 24.38 in

Dimensions

Product Depth (in.)

24.38 in

Product Height (in.)

24 in

Product Width (in.)

24.38 in

Details

Actual Solids Capacity

2 in.

Amperage (A)

12 A

Cord Length (ft.)

25 ft

Discharge Flow @ 0 ft. (gallons/hour)

7500

Discharge Flow @ 0 ft. (gallons/min)

125

Discharge Flow @ 10 ft. (gallons/hour)

7500

Discharge Flow @ 10 ft. (gallons/min)

125

Features

Thermal Overload Protection

Housing Material

Other

Impeller Material

VORTEX ENGINEERED POLYMER

Maximum Horsepower (hp)

2/5

Maximum Pressure (PSI)

0

Maximum Working Temperature (F)

140

Minimum Sump Basin Diameter

10 7/8 or Less

Minimum working temperature (F)

34

Outlet Connection

Plain end

Pack Size

1

Power Type Required

AC

Product Weight (lb.)

67 lb

Pump Switch Type

Electronic

Returnable

90-Day

Septic Pump Type

Effluent

Vertical Lift (ft.)

20

Voltage

115v

Warranty / Certifications

Certifications and Listings

CSA Certified, SSPMA Certified

Manufacturer Warranty

3 year

Questions & Answers

1Question
caret
Q:The wires to the pump seem to go through the vent opening. What is the strategy on this? How are you supposed to feed wires through the vent pipe? Thanks in advance for your answer
by|Feb 24, 2024
1 Answer
Answer This Question

A:  Great question. The 2” electrical connection is not a vent connection. It is only an electrical connection. This unit would be vented off the 3” inlet. If you scroll down the Home Depot product listing page you will come to a section entitled Product Details. If you expand that section, you will find PDFs of the product documents. Opening the Use and Care manual you will find a piping illustration on page 8 that includes the vent line.

by|Feb 26, 2024
