Model #CDU800

1/2 HP Cast Iron Sump Pump with Vertical Float Switch

  • Pumps up to 5100 GPH at 0 ft.
  • Rugged, submersible cast iron base and metal construction
  • Top suction design filters debris and minimizes clogging
  • See More Details

Frequently Bought Together

+
+
Price:

Product Overview

Wayne's CDU800 features a durable cast iron base and epoxy-coated housing for long life and quiet operation. This submersible pump is designed for small sump pits, as small as 11 in., the CDU series is one of the most popular replacement sump pumps in America. The ceramic mechanical seal assures long life in the most demanding applications and the 1-1/2 in. discharge allows easy installation. This powerful 1/2 HP sump, pumps up to 5100 GPH.
  • Submersible cast iron and coated steel sump pump with vertical float switch
  • Top suction pump design eliminates air locks and clogging from debris in bottom of sump pit
  • Epoxy-coated steel motor housing and rugged, cast iron pump base
  • Fully submersible
  • 1/2 HP; max. flow rate is 5100 GPH; 3840 GPH at 10 ft. of discharge lift
  • 1-1/2 in. NPT discharge
  • For use in 11 in. Dia or larger sump basins; 9 in. on level and 4 in. off level
  • Assembled in the U.S.A.
  • Additional Features:


  • Click here for more information on Electronic Recycling Programs

Info & Guides

You will need Adobe® Acrobat® Reader to view PDF documents. Download a free copy from the Adobe Web site.

Compare Similar Submersible Sump Pumps

current product
1/2 HP Cast Iron Sump Pump with Vertical Float Switch
WRSC-6 Compact Drainosaur 0.3 HP Water Removal Pump System92072 1/3 HP Pre-Assembled Submersible Remote Sink Drain Pump SystemExclusive3/10 HP Pre-Plumbed Sump Pump System
BrandWayneLittle GiantSuperior PumpEverbilt
Name1/2 HP Cast Iron Sump Pump with Vertical Float SwitchWRSC-6 Compact Drainosaur 0.3 HP Water Removal Pump System92072 1/3 HP Pre-Assembled Submersible Remote Sink Drain Pump System3/10 HP Pre-Plumbed Sump Pump System
Price
Ratings
(1120)
(24)
(78)
(26)
Voltage120v115v120v115v
Housing MaterialSteelCast-IronThermoplasticCast-Iron
Discharge Flow @ 0 ft. (gallons/hour)5100270028803160
View ProductView ProductView ProductView Product

Specifications

Dimensions

Product Depth (in.)
10 in
Product Height (in.)
14 in
Product Width (in.)
10 in
Switch-Off Height (in.)
4
Switch-On Height (in.)
9

Details

Amperage (amps)
3.8
Cord Length (ft.)
8
Discharge Flow @ 0 ft. (gallons/hour)
5100
Discharge Flow @ 0 ft. (gallons/min)
85
Discharge Flow @ 10 ft. (gallons/hour)
3840
Discharge Flow @ 10 ft. (gallons/min)
64
Discharge Flow @ 15 ft. (gallons/min)
51
Features
Non-Clogging,Submersible
Housing Material
Steel
Impeller Material
Plastic
Maximum Horsepower (hp)
1/2
Maximum Pressure (psi)
11.03896104
Maximum Working Temperature (F)
120
Minimum Sump Basin Diameter
11 to 14
Minimum working temperature (F)
40
Outlet Diameter Connection (in.)
1-1/2 FPT
Pack Size
1
Power Type Required
AC
Product Weight (lb.)
18.5 lb
Pump Switch Type
Vertical
Returnable
90-Day
Vertical Lift (ft.)
22
Voltage
120v

Warranty / Certifications

Certifications and Listings
cUL Listed
Manufacturer Warranty
3

Questions & Answers

173Questions20Answers

is there any reason why I should not connect the check valve directly to the sump pump discharge?

Asked by klokm March 14, 2021
2
Answers

No, I do it all the time. No problems

does this pump require a vent hole, and if so, where??

Asked by klokm March 14, 2021
5
Answers

Not sure who answered this, but if it was "youbigdummie", This was the best analysis and answer I've received. A little safe-fail seems good, requiring little effort, Thanks, klokm

please explain what the specification:---" 9 in. on level and 4 in. off level" means??

Asked by klokm March 14, 2021
3
Answers

1- The pump will start when the water level in the bottom has reached 9 in. depth. The ball will be up which triggers the electric switch on. 2- The pump will stop when the water level in the bottom is down to 4 in. depth. The ball will be down which triggers the electric switch off.

What size diameter of pipe do I need

Asked by Talltoo October 22, 2020
1
Answer

This is dependent on the application you have. the pump has a 1.5" diameter hole so you could use one of three sizes. There would be 1.5" or 1.25" or 2" if you need help narrowing it down please call our technical team and we will assist you.

What is the amperage drawn when the pump runs?

Asked by TJ October 5, 2020
1
Answer

Approximately 6 to 8 amps.

How many GpMs at 10 feet of lift?

Asked by nick September 11, 2020
1
Answer

4743 Gallons per Minute at 10 feet of lift. I hope that helps.

How many wats

Asked by Bob September 2, 2020
2
Answers

A 1/3 hp motor at 120 volts draws approximately 7.2 amps

Does Home Depot give recommendations for installing the Wane 1/2 hp sump pump?

Asked by Kitty August 28, 2020
1
Answer

I am a DIY'er that have read a lot of Questions and Anwers here on Home Depot for sump pumps and I see many Answers from Home Depot that Home Depot (and or the manufacturer) they will refer you to call the manufacturer with any help needed on installing. If your question is does Home Depot give recommendations for Home Depot to recommend an installer they may and you would need to call Home Depot. If you are asking does Home Depot recommend installation help, no I don't believe you will get any detailed installation information here on Home Depot from Home Depot or the manufacturer in Questions and Answers. Good luck either way.

Can this pump run continuously?? Can it replace a pedestal pump in a deep sump? In heavy rain my ...

Asked by Dusty August 4, 2020
1
Answer

This the best pump on the market for what you pay for it. I've use these pumps for 15 years with no failure. it will out perform your pedestal pump 5 times over. You should not run any pump continously, you will burn them out, not necessary. Set pump up with 1&1/2" to 2" pvc with check valve and your ready to go, it will keep up with your water flow, go for it.

Is the float solid or hollow?

Asked by Daniel August 4, 2020
3
Answers

SOLID

1/2 HP Cast Iron Sump Pump with Vertical Float Switch - page 2

Customer Reviews

  • 4.7
    out of 1,120 reviews
  • 93% recommend this product
Filter by:
Showing 1-10 of 1,120 reviews
How does the song go, "seems it never rains in Southern California, but girl, let me warn ya, it ...
How does the song go, "seems it never rains in Southern California, but girl, let me warn ya, it pours, man it pours”. We can get a lot of rain when the storms roll through, and some of it was beginning to flood our backyard and patio. Did a lot of research on the best pump, and liked the construction details, production tests, and warranty for this pump. Using it for our backyard drainage, it didn’t need to be the largest, and it has proven itself to be perfect for my intended usage. I installed a collection box at what was the lowest part of our yard (also from Home Depot, U.S. TRENCH DRAIN 18”x14” Storm Water Pit and Catch Basin for Modular Trench and Channel Drain Systems with Aluminum Grate), an Everbuilt Sump Pump check valve, and then ran 1 1/2” ABS out to an ABS drain line under our driveway, and continued that run down slope to off the curb. Anchored this box deep down with 10” lag screws through the box sides sideways to eliminate potential for the box to be floated by water. Placed the pump inside, where fit and room was perfect. As stated, this pump works perfectly for its intended use. Rain water runoff accumulates quickly in the box, the float rises as it fills and in less than 2 seconds the box is emptied. Over and over and over. I have stood in the rain and watched it repeat this action effortlessly as the rain pours down. It’s a pleasure to watch a project succeed in its purpose, and have a dry patio. I have the pump plugged into a waterproof passthrough into the house, with a portable GFCI at the outlet. The pump is quiet, efficient, feels very well built, is solid, and has good heft. The most I have heard is a low hum when it activates. It has given us a lot of peace of mind now knowing that we won’t wake to a flooded patio when it rains heavily overnight. I realize we have only started the rainy season as of this writing, but right now I am very satisfied with this purchase.
by DIYGal
2 people found this helpful
This product failed within 3 days--its switch stopped working properly. Repeatedly, this pump wo...
This product failed within 3 days--its switch stopped working properly. Repeatedly, this pump would stop operating even though the float was fully underwater. I would jostle the float a little, and the pump would start up, but then never cycle. An expert looked at the installation, made a small change, and said, "If it stops again, it has definitely failed." The pump stopped again that same day, and as my crawl space began to flood, I called the expert to replace this model with a different one.
by Auroran
2 people found this helpful
Wouldn't recommend Wayne pumps if you want one to last more than a couple of years. Installed one...
Wouldn't recommend Wayne pumps if you want one to last more than a couple of years. Installed one of their 1/3 hp pedestal sump pumps a few years ago in my mothers basement. It lasted about 2 years before the shaft rusted to the cast iron and it stopped working. Replaced it with another brand and threw the Wayne off to the side until a few days ago when I brought what was left of it home so I could at least harvest the motor off of it and throw the rust pile away. Total JUNK!
by catfish307
2 people found this helpful
I have had 3 major floods in a finished basement so i read the reviews to try and make sure i got...
I have had 3 major floods in a finished basement so i read the reviews to try and make sure i got the best pump i could buy. This item had great reviews and an industry leading 5 year warranty. Had in installed and it immediately stopped working. I found out that it is supposed to have a really thin rubber tether that connects to bottom of float and attaches to the pump. Mine was missing or fell off. In addition i thought this was an extremely poor design as the rubber will get dry rotted being in constant water and probably need replacing within a year. I called wayne and told them this and they informed me that this part was not covered under their 5 year warranty and should be replaced every year. Who ever heard of having to replace parts on a new sump pump every year!. In addition the pump had only been in my crock for 1 day and was already more rusted than the liberty pump i had in there for 10 years. I will never purchase a wayne again. Stick with liberty as they make much better quality pumps.
by Lyn
6 people found this helpful
It's hard to rate something that you will depend on for long term durability when just installing...
It's hard to rate something that you will depend on for long term durability when just installing it. Just 4 stars for that reason. However, it was easy to install and is extremely quiet.
by Sump1
Great sump pump! I was amazed at how quiet it is. It has my recommendation
Great sump pump! I was amazed at how quiet it is. It has my recommendation
by WayneSumpPump
My previously installed Wayne sump pump was still functioning ok but, not being sure how old it w...
My previously installed Wayne sump pump was still functioning ok but, not being sure how old it was, I decided to replace it a month ago for peace of mind reasons. The choice as to what to replace it with was easy to make - the same thing. I have about a ten foot lift to get the water out of the basement. The pumping power of this pump is more than adequate. I like the quality of cast iron construction. The vertical float switch design allows it to fit well into my sump pit and the float "guard" ensures that the pump cannot get close enough to the wall to interfere with the float. It is also very quiet. A great quality product. More than meets expectations.
by Bigdaddywease
6 people found this helpful
This 3/4 HP Sump Pump meets all my expectations: - Power is enough to clear water from 5 feet bel...
This 3/4 HP Sump Pump meets all my expectations: - Power is enough to clear water from 5 feet below. - Installation is easy, about 1/2 hour if you have the Quick Connect Tube from the Home Depot. - Just bought this pump on 04/20/2015 - It should be perfect if the Wayne Maker mentioned the quick connect tube or how to make it...
by HDFrequentBuyer
3 people found this helpful
I am very impressed.  For ease of installation, solid craftsmanship, and performance I give this ...
I am very impressed.  For ease of installation, solid craftsmanship, and performance I give this 5 stars. While doing my spring maintenance, I discovered that the sump pump that was installed in my house came from the early 1990's.  It had deteriorated pretty badly and I felt like replacing it as a preventative measure would be a good idea.  The model was a 1/3 hp with an outdated switch and float set-up. After looking over the various models available, I elected to pursue this.  Not only was it well reviewed, but it seemed solidly made, affordably priced, and more powerful than the unit I had previously.  I ordered it online and took advantage of the free shipping.  It showed up two days later, much to my surprise, and I immediately went to work.  This unit is magnitudes better than the one I had.  It was a joy to install, I simply cut new PVC and threaded an adapter onto it with some sealant.  The model I used was (http://www.homedepot.com/p/1-1-2-in-PVC-DWV-Hub-x-MIPT-Male-Adapter-C4804HD112/100347535). Once completed, I cleaned out my existing sump basin and placed this unit on the bottom.  After plugging it in, I decided to gather my wife for a test of this units capabilities.  We got several five gallon buckets and proceeded to fill the sump basin.  This unit kicked on and immediately went to work--it was quiet, efficient, and powerful.
by Tim
11 people found this helpful
Today, 3-21-17, is the first day Wayne 3/4 HP went to work. First day on the job and it's a heavy...
Today, 3-21-17, is the first day Wayne 3/4 HP went to work. First day on the job and it's a heavy downpour in the Sierra Foothills, CA. The vertical lift is about 4' 1/2" and travels about 34' horizontally at about a 15 or so degree slope. Wayne is still on probation but so far so good!
by JigglingH2O
2 people found this helpful
